The metal–oxide–semiconductor field-effect transistor (MOSFET, MOS-FET, or MOS FET), also known as the metal–oxide–silicon transistor (MOS transistor, or MOS),^[1] is a type of field-effect transistor that is fabricated by the controlled oxidation of a semiconductor, typically silicon. It has an insulated gate, whose voltage determines the conductivity of the device. This ability to change conductivity with the amount of applied voltage can be used for amplifying or switching electronic signals. It was invented by Egyptian engineer Mohamed M. Atalla and Korean engineer Dawon Kahng at Bell Labs in November 1959. The MOSFET is the basic building block of modern electronics, and the most widely manufactured device in history, with an estimated total of 13sextillion (1.3 × 10²²) MOSFETs manufactured between 1960 and 2018.

The MOSFET is by far the most widely used transistor in digital electronics as well as analog circuits, and is considered to be possibly the most important invention in electronics. It was the first truly compact transistor that could be miniaturised and mass-produced for a wide range of uses, revolutionizing the electronics industry and in turn the world economy. It has been central to the microcomputer revolution, digital revolution, information revolution, silicon age, and information age. MOSFETs are the basis for high-densityintegrated circuits (ICs) such as memory chips and microprocessors, and in turn modern computers and mobile devices, each typically using millions to billions of MOSFETs. Discrete power MOSFETs are also the most common power devices. MOSFETs are used for numerous applications, such as computers, smart devices, telecommunications, power supplies, RF amplifiers, audio amplifiers, electronic musical instruments, display devices, television receivers, image sensors, automotive electronics, the Internet, wireless mobile networks, home entertainment, video games, industrial equipment, pocket calculators, X-ray detectors, spacecraft, and satellites, among many other uses. The US Patent and Trademark Office calls the MOSFET a 'groundbreaking invention that transformed life and culture around the world'.

A key advantage of a MOSFET is that it requires almost no input current to control the load current, when compared with bipolar transistors (bipolar junction transistors, or BJTs). In an enhancement mode MOSFET, voltage applied to the gate terminal increases the conductivity of the device. In depletion mode transistors, voltage applied at the gate reduces the conductivity.^[2] MOSFETs are also capable of high scalability (Moore's law and Dennard scaling),^[3] with increasing miniaturisation,^[4] and can be easily scaled down to smaller dimensions.^[5] They also consume much less power, and allow higher density, than bipolar transistors.^[6] The MOSFET is also cheaper^[7] and has relatively simple processing steps, resulting in a high manufacturing yield.^[5] Since MOSFETs can be made with either p-type or n-type semiconductors (PMOS or NMOS logic, respectively), complementary pairs of MOS transistors can be used to make switching circuits with very low power consumption, in the form of CMOS (complementary MOS) logic.

The name 'metal–oxide–semiconductor' (MOS) typically refers to a metal gate, oxide insulation, and semiconductor (typically silicon).^[1] However, the 'metal' in the name MOSFET is sometimes a misnomer, because the gate material can also be a layer of polysilicon (polycrystalline silicon). Along with oxide, different dielectric materials can also be used with the aim of obtaining strong channels with smaller applied voltages.

• 1Origins
• 4Operation
• 6Types of MOSFET
• 7Applications
  • 7.1MOS integrated circuits
  • 7.2CMOS circuits
  • 7.3Analog switches
  • 7.4Power electronics
• 8Construction
• 10Timeline

Origins[edit]

Background[edit]

The basic principle of the field-effect transistor (FET) was first proposed by Austro-Hungarian physicist Julius Edgar Lilienfeld in 1925.^[8] However, his early FET concept was not a practical design.^[9] The FET concept was later also theorized by Oskar Heil in the 1930s and William Shockley in the 1940s,^[10] but there was no working practical FET built at the time.^[9] Shockley's research team initially attempted to build a working FET, by trying to modulate the conductivity of a semiconductor, but they were unsuccessful, mainly due to problems with the surface states, the dangling bond, and the germanium and copper compound materials. In the course of trying to understand the mysterious reasons behind their failure to build a working FET, this led them to instead invent the bipolar point-contact and junction transistors.^[11][12] None of these early FET proposals involved thermally oxidizedsilicon, which later made the MOS transistor possible.^[13] Semiconductor companies initially focused on junction transistors in the early years of the semiconductor industry. However, the junction transistor was a relatively bulky device that was difficult to manufacture on a mass-production basis, which limited it to a number of specialised applications. FETs were theorized as potential alternatives to junction transistors, but researchers could not get FETs to work properly, largely due to the troublesome surface state barrier that prevented the external electric field from penetrating into the material.^[14]

Invention[edit]

A breakthrough came with the work of Egyptian engineer Mohamed M. Atalla in the late 1950s.^[12] He investigated the surface properties of silicon semiconductors at Bell Labs, where he adopted a new method of semiconductor device fabrication, coating a silicon wafer with an insulating layer of silicon oxide, so that electricity could reliably penetrate to the conducting silicon below, overcoming the surface states that prevented electricity from reaching the semiconducting layer. This is known as surface passivation, a method that later became critical to the semiconductor industry as it made possible the mass-production of silicon semiconductor technology, such as integrated circuit (IC) chips.^[9][15][16] For the surface passivation process, he developed the method of thermal oxidation, which was a breakthrough in silicon semiconductor technology.^[17] The surface passivation method, which substantially reduced the influence of the dangling bond that had prevented Shockley's research team from building a working FET,^[12] was presented by Atalla in 1957.^[18] Building on the surface passivation method, Atalla developed the metal–oxide–semiconductor (MOS) process,^[15] with the use of thermally oxidized silicon.^[13][19] He proposed that the MOS process could be used to build the first working silicon FET, which he began working on building with the help of Korean recruit Dawon Kahng.^[15]

The MOSFET was invented by Mohamed Atalla and Dawon Kahng in 1959.^[10][16] They fabricated the device in November 1959,^[20] and presented it as the 'silicon–silicon dioxide field induced surface device' in early 1960,^[21] at the Solid-State Device Conference held at Carnegie Mellon University.^[22] The device is covered by two patents, each filed separately by Atalla and Kahng in March 1960.^[23][24] Operationally and structurally different from the bipolar junction transistor,^[25] the MOSFET was made by putting an insulating layer on the surface of the semiconductor and then placing a metallic gate electrode on that. It used crystalline silicon for the semiconductor and a thermally oxidized layer of silicon dioxide for the insulator. The silicon MOSFET did not generate localized electron traps at the interface between the silicon and its native oxide layer, and thus was inherently free from the trapping and scattering of carriers that had impeded the performance of earlier attempts at building a field-effect transistor.

Commercialization[edit]

The MOSFET was the first truly compact transistor that could be miniaturised and mass-produced for a wide range of uses.^[14] Despite the breakthrough, the MOSFET was initially overlooked and ignored by Bell Labs in favour of bipolar transistors, which led to Atalla resigning from Bell Labs and joining Hewlett Packard in 1961.^[16] However, the MOSFET generated significant interest at RCA and Fairchild Semiconductor.^[10] In December 1960, Karl Zaininger and Charles Meuller at RCA began fabricating a MOS device based on Atalla's device.^[26] Similarly based on Atalla's work,^[27]Chih-Tang Sah at Fairchild in late 1960 began building an MOS-controlled tetrode,^[10] which he presented in 1961.^[28] MOS devices were later commercialized by General Microelectronics and Fairchild in 1964, with p-channel devices for logic and switching applications.^[10] The development of MOS technology, which was capable of increasing miniaturisation, eventually became the focus of RCA, Fairchild, Intel and other semiconductor companies in the 1960s, fuelling the technological and economic growth of the early semiconductor industry in California (centred around what later became known as Silicon Valley)^[29] as well as Japan.^[30]

Importance[edit]

The MOSFET forms the basis of modern electronics,^[31] and is the basic element in most modern electronic equipment.^[32] It is the most widely used semiconductor device in the world,^[33] and the most common transistor in electronics^[9] and communications technology.^[34] It has been described as the 'workhorse of the electronics industry' due to being the building block of every microprocessor, memory chip and telecommunication circuit in use,^[35] as well as siliconintegrated circuits (ICs),^[36]visual displays,^[37] digital wirelesstelecommunication networks,^[38][39]graphics processing units (GPU),^[40] the computer industry, digital telecommunication systems, video games, pocket calculators, and digital wristwatches, among many other uses.^[41]

The MOSFET was the first truly compact transistor that could be miniaturised and mass-produced for a wide range of uses.^[14] This led to a revolution in the electronics industry, which has since impacted daily life in almost every way.^[42] The MOSFET has been called the most important transistor,^[43] the most important device in the electronics industry,^[44] the most important device in the computing industry,^[45] one of the most important developments in semiconductor technology,^[46] the birth of modern electronics,^[47] and possibly the most important invention in electronics.^[48]

The MOSFET is the most widely manufactured device in history.^[49][50] The MOSFET generates annual sales of $295 billion as of 2015.^[51] Between 1960 and 2018, an estimated total of 13sextillion MOS transistors have been manufactured, accounting for at least 99.9% of all transistors.^[49] Digital integrated circuits such as microprocessors and memory devices contain thousands to billions of integrated MOSFET transistors on each device, providing the basic switching functions required to implement logic gates and data storage. There are also memory devices which contain at least a trillion MOS transistors, such as a 256GBmicroSDmemory card, larger than the number of stars in the Milky Waygalaxy.^[35]

Some of the earliest electronic fields to be revolutionized by the MOSFET include power electronics,^[52] electronic signal processing, control systems, and computers.^[53] The MOSFET was central to the electronics revolution,^[54]microelectronics revolution,^[55]silicon revolution,^[56][57] and microcomputer revolution,^[58] and has been the fundamental building block of modern digital electronics during the digital revolution, information revolution, information age,^{[59][60][61][62]} and silicon age.^[56][57] MOSFETs have been the driving force behind the computer revolution, and the technologies enabled by it, such as computers, the Internet, and smartphones.^[34][63] The rapid progress of the electronics industry during the late 20th to early 21st centuries was achieved by rapid MOSFET scaling (Dennard scaling and Moore's law), down to the level of nanoelectronics in the early 21st century.^[64]

Power MOSFETs and MOS integrated circuits are fundamental to the Internet, and the communications infrastructure that enables the Internet.^[65][66] MOSFETs are fundamental to digital wireless telecommunication networks, such as mobile networks.^[38][39] Most of the essential elements of mobile networks use MOSFETs, including the handheld mobile devices themselves, along with the mobile tranceivers, base station modules, routers, and RF power amplifiers.^[39] Advances in MOS technology has been the most important contributing factor in the rapid rise of internet access bandwidth in telecommunications networks, with online bandwidth doubling every 18 months, from bits per second to terabits per second.^[67] The thin-film transistor (TFT), a type of MOSFET,^[37] is the basis for display technologies such as TFT LCDs (liquid-crystal displays), LCD televisions,^[68]active-matrix LCD (AM LCD), and OLED (organic light-emitting diode), as well as X-ray detectors.^[69]

The mass-production of silicon MOSFETs and MOS integrated circuit chips, along with continuous MOSFET scaling miniaturization at an exponential pace (as predicted by Moore's law), has led to revolutionary changes in technology, economy, culture and thinking.^[56] The US Patent and Trademark Office calls the MOSFET a 'groundbreaking invention that transformed life and culture around the world'^[34] and the Computer History Museum credits it with 'irrevocably changing the human experience' as 'the base technology' of the late 20th to early 21st centuries.^[59] The MOSFET is included on the list of IEEE milestones in electronics,^[70] and its inventors Mohamed Atalla and Dawon Kahng entered the National Inventors Hall of Fame in 2009.^[9][15] The MOSFET was the basis for Nobel Prize winning breakthroughs such as the quantum Hall effect^[71] and the charge-coupled device (CCD),^[72] yet there was never any Nobel Prize given for the MOSFET itself.^[73] In 2018, the Royal Swedish Academy of Sciences which awards the science Nobel Prizes acknowledged that the invention of the MOSFET by Atalla and Kahng was one of the most important inventions in microelectronics and in information and communications technology (ICT).^[74]

Composition[edit]

Usually the semiconductor of choice is silicon. Recently, some chip manufacturers, most notably IBM and Intel, have started using a chemical compound of silicon and germanium (SiGe) in MOSFET channels. Unfortunately, many semiconductors with better electrical properties than silicon, such as gallium arsenide, do not form good semiconductor-to-insulator interfaces, and thus are not suitable for MOSFETs. Research continues^[when?] on creating insulators with acceptable electrical characteristics on other semiconductor materials.

To overcome the increase in power consumption due to gate current leakage, a high-κ dielectric is used instead of silicon dioxide for the gate insulator, while polysilicon is replaced by metal gates (e.g. Intel, 2009^[75]).

The gate is separated from the channel by a thin insulating layer, traditionally of silicon dioxide and later of silicon oxynitride. Some companies have started to introduce a high-κ dielectric and metal gate combination in the 45 nanometer node.

When a voltage is applied between the gate and body terminals, the electric field generated penetrates through the oxide and creates an inversion layer or channel at the semiconductor-insulator interface. The inversion layer provides a channel through which current can pass between source and drain terminals. Varying the voltage between the gate and body modulates the conductivity of this layer and thereby controls the current flow between drain and source. This is known as enhancement mode.

Operation[edit]

Metal–oxide–semiconductor structure[edit]

The traditional metal–oxide–semiconductor (MOS) structure is obtained by growing a layer of silicon dioxide (SiO
₂) on top of a silicon substrate, commonly by thermal oxidation and depositing a layer of metal or polycrystalline silicon (the latter is commonly used). As the silicon dioxide is a dielectric material, its structure is equivalent to a planar capacitor, with one of the electrodes replaced by a semiconductor.

When a voltage is applied across a MOS structure, it modifies the distribution of charges in the semiconductor. If we consider a p-type semiconductor (with ${\displaystyle N_{\text{A}}}$ the density of acceptors, p the density of holes; p = N_A in neutral bulk), a positive voltage, ${\displaystyle V_{\text{GB}}}$, from gate to body (see figure) creates a depletion layer by forcing the positively charged holes away from the gate-insulator/semiconductor interface, leaving exposed a carrier-free region of immobile, negatively charged acceptor ions (see doping (semiconductor)). If ${\displaystyle V_{\text{GB}}}$ is high enough, a high concentration of negative charge carriers forms in an inversion layer located in a thin layer next to the interface between the semiconductor and the insulator.

Conventionally, the gate voltage at which the volume density of electrons in the inversion layer is the same as the volume density of holes in the body is called the threshold voltage. When the voltage between transistor gate and source (V_GS) exceeds the threshold voltage (V_th), the difference is known as overdrive voltage.

This structure with p-type body is the basis of the n-type MOSFET, which requires the addition of n-type source and drain regions.

MOS capacitors and band diagrams[edit]

The MOS capacitor structure is the heart of the MOSFET. Consider a MOS capacitor where the silicon base is of p-type. If a positive voltage is applied at the gate, holes which are at the surface of the p-type substrate will be repelled by the electric field generated by the voltage applied. At first, the holes will simply be repelled and what will remain on the surface will be immobile (negative) atoms of the acceptor type, which creates a depletion region on the surface. Remember that a hole is created by an acceptor atom, e.g. Boron, which has one less electron than Silicon. One might ask how can holes be repelled if they are actually non-entities? The answer is that what really happens is not that a hole is repelled, but electrons are attracted by the positive field, and fill these holes, creating a depletion region where no charge carriers exist because the electron is now fixed onto the atom and immobile.

As the voltage at the gate increases, there will be a point at which the surface above the depletion region will be converted from p-type into n-type, as electrons from the bulk area will start to get attracted by the larger electric field. This is known as inversion. The threshold voltage at which this conversion happens is one of the most important parameters in a MOSFET.

In the case of a p-type bulk, inversion happens when the intrinsic energy level at the surface becomes smaller than the Fermi level at the surface. One can see this from a band diagram. Remember that the Fermi level defines the type of semiconductor in discussion. If the Fermi level is equal to the Intrinsic level, the semiconductor is of intrinsic, or pure type. If the Fermi level lies closer to the conduction band (valence band) then the semiconductor type will be of n-type (p-type). Therefore, when the gate voltage is increased in a positive sense (for the given example), this will 'bend' the intrinsic energy level band so that it will curve downwards towards the valence band. If the Fermi level lies closer to the valence band (for p-type), there will be a point when the Intrinsic level will start to cross the Fermi level and when the voltage reaches the threshold voltage, the intrinsic level does cross the Fermi level, and that is what is known as inversion. At that point, the surface of the semiconductor is inverted from p-type into n-type. Remember that as said above, if the Fermi level lies above the Intrinsic level, the semiconductor is of n-type, therefore at Inversion, when the Intrinsic level reaches and crosses the Fermi level (which lies closer to the valence band), the semiconductor type changes at the surface as dictated by the relative positions of the Fermi and Intrinsic energy levels.

Structure and channel formation[edit]

A MOSFET is based on the modulation of charge concentration by a MOS capacitance between a body electrode and a gate electrode located above the body and insulated from all other device regions by a gate dielectric layer. If dielectrics other than an oxide are employed, the device may be referred to as a metal-insulator-semiconductor FET (MISFET). Compared to the MOS capacitor, the MOSFET includes two additional terminals (source and drain), each connected to individual highly doped regions that are separated by the body region. These regions can be either p or n type, but they must both be of the same type, and of opposite type to the body region. The source and drain (unlike the body) are highly doped as signified by a '+' sign after the type of doping.

If the MOSFET is an n-channel or nMOS FET, then the source and drain are n+ regions and the body is a p region. If the MOSFET is a p-channel or pMOS FET, then the source and drain are p+ regions and the body is a n region. The source is so named because it is the source of the charge carriers (electrons for n-channel, holes for p-channel) that flow through the channel; similarly, the drain is where the charge carriers leave the channel.

The occupancy of the energy bands in a semiconductor is set by the position of the Fermi level relative to the semiconductor energy-band edges.

With sufficient gate voltage, the valence band edge is driven far from the Fermi level, and holes from the body are driven away from the gate.

At larger gate bias still, near the semiconductor surface the conduction band edge is brought close to the Fermi level, populating the surface with electrons in an inversion layer or n-channel at the interface between the p region and the oxide. This conducting channel extends between the source and the drain, and current is conducted through it when a voltage is applied between the two electrodes. Increasing the voltage on the gate leads to a higher electron density in the inversion layer and therefore increases the current flow between the source and drain. For gate voltages below the threshold value, the channel is lightly populated, and only a very small subthreshold leakage current can flow between the source and the drain.

When a negative gate-source voltage (positive source-gate) is applied, it creates a p-channel at the surface of the n region, analogous to the n-channel case, but with opposite polarities of charges and voltages. When a voltage less negative than the threshold value (a negative voltage for the p-channel) is applied between gate and source, the channel disappears and only a very small subthreshold current can flow between the source and the drain. The device may comprise a silicon on insulator device in which a buried oxide is formed below a thin semiconductor layer. If the channel region between the gate dielectric and the buried oxide region is very thin, the channel is referred to as an ultrathin channel region with the source and drain regions formed on either side in or above the thin semiconductor layer. Other semiconductor materials may be employed. When the source and drain regions are formed above the channel in whole or in part, they are referred to as raised source/drain regions.

Modes of operation[edit]

The operation of a MOSFET can be separated into three different modes, depending on the voltages at the terminals. In the following discussion, a simplified algebraic model is used.^[78] Modern MOSFET characteristics are more complex than the algebraic model presented here.^[79]

For an enhancement-mode, n-channel MOSFET, the three operational modes are:

Cutoff, subthreshold, and weak-inversion mode

When V_GS < V_th:

where ${\displaystyle V_{\text{GS}}}$ is gate-to-source bias and ${\displaystyle V_{\text{th}}}$ is the threshold voltage of the device.

According to the basic threshold model, the transistor is turned off, and there is no conduction between drain and source. A more accurate model considers the effect of thermal energy on the Fermi–Dirac distribution of electron energies which allow some of the more energetic electrons at the source to enter the channel and flow to the drain. This results in a subthreshold current that is an exponential function of gate-source voltage. While the current between drain and source should ideally be zero when the transistor is being used as a turned-off switch, there is a weak-inversion current, sometimes called subthreshold leakage.

In weak inversion where the source is tied to bulk, the current varies exponentially with ${\displaystyle V_{\text{GS}}}$ as given approximately by:^[80][81]

${\displaystyle I_{\text{D}}\approx I_{\text{D0}}{e}^{\frac{V_{\text{GS}}-V_{\text{th}}}{n{V}_{\text{T}}}},}$

where ${\displaystyle I_{\text{D0}}}$ = current at ${\displaystyle V_{\text{GS}}=V_{\text{th}}}$, the thermal voltage ${\displaystyle V_{\text{T}}=kT/q}$ and the slope factor n is given by:

${\displaystyle n=1+\frac{C_{\text{dep}}}{C_{\text{ox}}},}$

with ${\displaystyle C_{\text{dep}}}$ = capacitance of the depletion layer and ${\displaystyle C_{\text{ox}}}$ = capacitance of the oxide layer. This equation is generally used, but is only an adequate approximation for the source tied to the bulk. For the source not tied to the bulk, the subthreshold equation for drain current in saturation is^[82][83]

${\displaystyle I_{\text{D}}\approx I_{\text{D0}}{e}^{\frac{\kappa \left(V_{\text{G}}-V_{\text{th}}\right)-V_{\text{S}}}{V_{\text{T}}}},}$

where the ${\displaystyle \kappa }$ is the channel divider that is given by:

${\displaystyle \kappa =\frac{C_{\text{ox}}}{C_{\text{ox}}+C_{\text{D}}},}$

with ${\displaystyle C_{\text{D}}}$ = capacitance of the depletion layer and ${\displaystyle C_{\text{ox}}}$ = capacitance of the oxide layer. In a long-channel device, there is no drain voltage dependence of the current once ${\displaystyle V_{\text{DS}}\gg V_{\text{T}}}$, but as channel length is reduced drain-induced barrier lowering introduces drain voltage dependence that depends in a complex way upon the device geometry (for example, the channel doping, the junction doping and so on). Frequently, threshold voltage V_th for this mode is defined as the gate voltage at which a selected value of current I_D0 occurs, for example, I_D0 = 1μA, which may not be the same V_th-value used in the equations for the following modes.

Some micropower analog circuits are designed to take advantage of subthreshold conduction.^[84][85][86] By working in the weak-inversion region, the MOSFETs in these circuits deliver the highest possible transconductance-to-current ratio, namely: ${\displaystyle g_m/I_{\text{D}}=1/\left(n{V}_{\text{T}}\right)}$, almost that of a bipolar transistor.^[87]

The subthreshold I–V curve depends exponentially upon threshold voltage, introducing a strong dependence on any manufacturing variation that affects threshold voltage; for example: variations in oxide thickness, junction depth, or body doping that change the degree of drain-induced barrier lowering. The resulting sensitivity to fabricational variations complicates optimization for leakage and performance.^[88][89]

Triode mode or linear region (also known as the ohmic mode^[90][91])

When V_GS > V_th and V_DS < V_GS − V_th:

The transistor is turned on, and a channel has been created which allows current between the drain and the source. The MOSFET operates like a resistor, controlled by the gate voltage relative to both the source and drain voltages. The current from drain to source is modeled as:

${\displaystyle I_{\text{D}}={\mu }_n{C}_{\text{ox}}\frac{W}{L}\left(\left(V_{\text{GS}}-V_{\mathrm{t}\mathrm{h}}\right)V_{\text{DS}}-\frac{{V_{\text{DS}}}^2}{2}\right)}$

where ${\displaystyle {\mu }_n}$ is the charge-carrier effective mobility, ${\displaystyle W}$ is the gate width, ${\displaystyle L}$ is the gate length and ${\displaystyle C_{\text{ox}}}$ is the gate oxide capacitance per unit area. The transition from the exponential subthreshold region to the triode region is not as sharp as the equations suggest.

Saturation or active mode^[92][93]

When V_GS > V_th and V_DS ≥ (V_GS – V_th):

The switch is turned on, and a channel has been created, which allows current between the drain and source. Since the drain voltage is higher than the source voltage, the electrons spread out, and conduction is not through a narrow channel but through a broader, two- or three-dimensional current distribution extending away from the interface and deeper in the substrate. The onset of this region is also known as pinch-off to indicate the lack of channel region near the drain. Although the channel does not extend the full length of the device, the electric field between the drain and the channel is very high, and conduction continues. The drain current is now weakly dependent upon drain voltage and controlled primarily by the gate-source voltage, and modeled approximately as:

${\displaystyle I_{\text{D}}=\frac{{\mu }_n{C}_{\text{ox}}}{2}\frac{W}{L}{\left[V_{\text{GS}}-V_{\text{th}}\right]}^2\left[1+\lambda (V_{\text{DS}}-V_{\text{DSsat}})\right].}$

The additional factor involving λ, the channel-length modulation parameter, models current dependence on drain voltage due to the Early effect, or channel length modulation. According to this equation, a key design parameter, the MOSFET transconductance is:

${\displaystyle g_m=\frac{\mathrm{\partial }{I}_D}{\mathrm{\partial }{V}_{\text{GS}}}=\frac{2I_{\text{D}}}{V_{\text{GS}}-V_{\text{th}}}=\frac{2I_{\text{D}}}{V_{\text{ov}}},}$

where the combination V_ov = V_GS − V_th is called the overdrive voltage,^[94] and where V_DSsat = V_GS − V_th accounts for a small discontinuity in ${\displaystyle I_{\text{D}}}$ which would otherwise appear at the transition between the triode and saturation regions.

Another key design parameter is the MOSFET output resistance r_out given by:

${\displaystyle r_{\text{out}}=\frac{1}{\lambda I_{\text{D}}}}$.

r_out is the inverse of g_DS where ${\displaystyle g_{\text{DS}}=\frac{\mathrm{\partial }{I}_{\text{DS}}}{\mathrm{\partial }{V}_{\text{DS}}}}$. I_D is the expression in saturation region.

If λ is taken as zero, an infinite output resistance of the device results that leads to unrealistic circuit predictions, particularly in analog circuits.

As the channel length becomes very short, these equations become quite inaccurate. New physical effects arise. For example, carrier transport in the active mode may become limited by velocity saturation. When velocity saturation dominates, the saturation drain current is more nearly linear than quadratic in V_GS. At even shorter lengths, carriers transport with near zero scattering, known as quasi-ballistic transport. In the ballistic regime, the carriers travel at an injection velocity that may exceed the saturation velocity and approaches the Fermi velocity at high inversion charge density. In addition, drain-induced barrier lowering increases off-state (cutoff) current and requires an increase in threshold voltage to compensate, which in turn reduces the saturation current.

Body effect[edit]

The occupancy of the energy bands in a semiconductor is set by the position of the Fermi level relative to the semiconductor energy-band edges. Application of a source-to-substrate reverse bias of the source-body pn-junction introduces a split between the Fermi levels for electrons and holes, moving the Fermi level for the channel further from the band edge, lowering the occupancy of the channel. The effect is to increase the gate voltage necessary to establish the channel, as seen in the figure. This change in channel strength by application of reverse bias is called the 'body effect'.

Simply put, using an nMOS example, the gate-to-body bias V_GB positions the conduction-band energy levels, while the source-to-body bias V_SB positions the electron Fermi level near the interface, deciding occupancy of these levels near the interface, and hence the strength of the inversion layer or channel.

The body effect upon the channel can be described using a modification of the threshold voltage, approximated by the following equation:

${\displaystyle V_{\text{TB}}=V_{T0}+\gamma \left(\sqrt{V_{\text{SB}}+2{\phi }_B}-\sqrt{2{\phi }_B}\right),}$

where V_TB is the threshold voltage with substrate bias present, and V_T0 is the zero-V_SB value of threshold voltage, ${\displaystyle \gamma }$ is the body effect parameter, and 2φ_B is the approximate potential drop between surface and bulk across the depletion layer when V_SB = 0 and gate bias is sufficient to ensure that a channel is present.^[95] As this equation shows, a reverse bias V_SB > 0 causes an increase in threshold voltage V_TB and therefore demands a larger gate voltage before the channel populates.

The body can be operated as a second gate, and is sometimes referred to as the 'back gate'; the body effect is sometimes called the 'back-gate effect'.^[96]

Circuit symbols[edit]

A variety of symbols are used for the MOSFET. The basic design is generally a line for the channel with the source and drain leaving it at right angles and then bending back at right angles into the same direction as the channel. Sometimes three line segments are used for enhancement mode and a solid line for depletion mode (see depletion and enhancement modes). Another line is drawn parallel to the channel for the gate.

The bulk or body connection, if shown, is shown connected to the back of the channel with an arrow indicating pMOS or nMOS. Arrows always point from P to N, so an NMOS (N-channel in P-well or P-substrate) has the arrow pointing in (from the bulk to the channel). If the bulk is connected to the source (as is generally the case with discrete devices) it is sometimes angled to meet up with the source leaving the transistor. If the bulk is not shown (as is often the case in IC design as they are generally common bulk) an inversion symbol is sometimes used to indicate PMOS, alternatively an arrow on the source may be used in the same way as for bipolar transistors (out for nMOS, in for pMOS).

Comparison of enhancement-mode and depletion-mode MOSFET symbols, along with JFET symbols. The orientation of the symbols, (most significantly the position of source relative to drain) is such that more positive voltages appear higher on the page than less positive voltages, implying current flowing 'down' the page:^[97][98][99]

In schematics where G, S, D are not labeled, the detailed features of the symbol indicate which terminal is source and which is drain. For enhancement-mode and depletion-mode MOSFET symbols (in columns two and five), the source terminal is the one connected to the triangle. Additionally, in this diagram, the gate is shown as an 'L' shape, whose input leg is closer to S than D, also indicating which is which. However, these symbols are often drawn with a 'T' shaped gate (as elsewhere on this page), so it is the triangle which must be relied upon to indicate the source terminal.

For the symbols in which the bulk, or body, terminal is shown, it is here shown internally connected to the source (i.e., the black triangles in the diagrams in columns 2 and 5). This is a typical configuration, but by no means the only important configuration. In general, the MOSFET is a four-terminal device, and in integrated circuits many of the MOSFETs share a body connection, not necessarily connected to the source terminals of all the transistors.

Types of MOSFET[edit]

PMOS and NMOS logic[edit]

P-type MOS (PMOS) logic uses p-channel MOSFETs to implement logic gates and other digital circuits. N-type MOS (NMOS) logic uses n-channel MOSFETs to implement logic gates and other digital circuits.

For devices of equal current driving capability, n-channel MOSFETs can be made smaller than p-channel MOSFETs, due to p-channel charge carriers (holes) having lower mobility than do n-channel charge carriers (electrons), and producing only one type of MOSFET on a silicon substrate is cheaper and technically simpler. These were the driving principles in the design of NMOS logic which uses n-channel MOSFETs exclusively. However, neglecting leakage current, unlike CMOS logic, NMOS logic consumes power even when no switching is taking place.

Mohamed Atalla and Dawon Kahng, after they invented the MOSFET, fabricated both pMOS and nMOS devices with a 20 µm process in 1960.^[16] Their original MOSFET devices had a gate length of 20µm and a gate oxide thickness of 100 nm.^[100] However, the nMOS devices were impractical, and only the pMOS type were practical working devices.^[16] A more practical NMOS process was developed several years later. NMOS was initially faster than CMOS, thus NMOS was more widely used for computers in the 1970s.^[101] With advances in technology, CMOS logic displaced NMOS logic in the mid-1980s to become the preferred process for digital chips.

Complementary MOS (CMOS)[edit]

The MOSFET is used in digital complementary metal–oxide–semiconductor (CMOS) logic,^[102] which uses p- and n-channel MOSFETs as building blocks. Overheating is a major concern in integrated circuits since ever more transistors are packed into ever smaller chips. CMOS logic reduces power consumption because no current flows (ideally), and thus no power is consumed, except when the inputs to logic gates are being switched. CMOS accomplishes this current reduction by complementing every nMOSFET with a pMOSFET and connecting both gates and both drains together. A high voltage on the gates will cause the nMOSFET to conduct and the pMOSFET not to conduct and a low voltage on the gates causes the reverse. During the switching time as the voltage goes from one state to another, both MOSFETs will conduct briefly. This arrangement greatly reduces power consumption and heat generation.

CMOS was developed by Chih-Tang Sah and Frank Wanlass at Fairchild Semiconductor in 1963.^[103] CMOS had lower power consumption, but was initially slower than NMOS, which was more widely used for computers in the 1970s. In 1978, Hitachi introduced the twin-well CMOS process, which allowed CMOS to match the performance of NMOS with less power consumption. The twin-well CMOS process eventually overtook NMOS as the most common semiconductor manufacturing process for computers in the 1980s.^[101]

Floating-gate MOSFET (FGMOS)[edit]

The floating-gate MOSFET (FGMOS) is a type of MOSFET where the gate is electrically isolated, creating a floating node in DC, and a number of secondary gates or inputs are deposited above the floating gate (FG) and are electrically isolated from it. The first report of a floating-gate MOSFET (FGMOS) was made by Dawon Kahng (co-inventor of the original MOSFET) and Simon Sze in 1967.^[104]

The FGMOS is commonly used as a floating-gate memory cell, the digital storage element in EPROM, EEPROM and flash memories. Other uses of the FGMOS include a neuronal computational element in neural networks, analog storage element, digital potentiometers and single-transistor DACs.

Depletion-mode[edit]

There are depletion-mode MOSFET devices, which are less commonly used than the standard enhancement-mode devices already described. These are MOSFET devices that are doped so that a channel exists even with zero voltage from gate to source. To control the channel, a negative voltage is applied to the gate (for an n-channel device), depleting the channel, which reduces the current flow through the device. In essence, the depletion-mode device is equivalent to a normally closed (on) switch, while the enhancement-mode device is equivalent to a normally open (off) switch.^[105]

Due to their low noise figure in the RF region, and better gain, these devices are often preferred to bipolars in RF front-ends such as in TV sets.

Depletion-mode MOSFET families include BF960 by Siemens and Telefunken, and the BF980 in the 1980s by Philips (later to become NXP Semiconductors), whose derivatives are still used in AGC and RF mixer front-ends.

Metal-insulator-semiconductor field-effect transistor (MISFET)[edit]

Metal-insulator-semiconductor field-effect-transistor,^{[106][107][108]} or MISFET, is a more general term than MOSFET and a synonym to insulated-gate field-effect transistor (IGFET). All MOSFETs are MISFETs, but not all MISFETs are MOSFETs.

The gate dielectric insulator in a MISFET is silicon dioxide in a MOSFET, but other materials can also be employed. The gate dielectric lies directly below the gate electrode and above the channel of the MISFET. The term metal is historically used for the gate material, even though now it is usually highly dopedpolysilicon or some other non-metal.

Insulator types may be:

• Silicon dioxide, in MOSFETs
• Organic insulators (e.g., undoped trans-polyacetylene; cyanoethyl pullulan, CEP^[109]), for organic-based FETs.^[108]

Thin-film transistor (TFT)[edit]

The thin-film transistor (TFT) is a type of MOSFET distinct from the standard bulk MOSFET.^[37] The first TFT was invented by Paul K. Weimer at RCA in 1962, building on the earlier work of Atalla and Kahng on MOSFETs.^[110]

The idea of a TFT-based liquid-crystal display (LCD) was conceived by Bernard Lechner of RCA Laboratories in 1968.^[111] Lechner, F. J. Marlowe, E. O. Nester and J. Tults demonstrated the concept in 1968 with an 18x2 matrix dynamic scattering LCD that used standard discrete MOSFETs, as TFT performance was not adequate at the time.^[112]

Power MOSFET[edit]

Power MOSFETs have a different structure.^[113] As with most power devices, the structure is vertical and not planar. Using a vertical structure, it is possible for the transistor to sustain both high blocking voltage and high current. The voltage rating of the transistor is a function of the doping and thickness of the N-epitaxial layer (see cross section), while the current rating is a function of the channel width (the wider the channel, the higher the current). In a planar structure, the current and breakdown voltage ratings are both a function of the channel dimensions (respectively width and length of the channel), resulting in inefficient use of the 'silicon estate'. With the vertical structure, the component area is roughly proportional to the current it can sustain, and the component thickness (actually the N-epitaxial layer thickness) is proportional to the breakdown voltage.^[114]

Power MOSFETs with lateral structure are mainly used in high-end audio amplifiers and high-power PA systems. Their advantage is a better behaviour in the saturated region (corresponding to the linear region of a bipolar transistor) than the vertical MOSFETs. Vertical MOSFETs are designed for switching applications.^[115]

The power MOSFET, which is commonly used in power electronics, was developed in the early 1970s.^[116] The power MOSFET enables low gate drive power, fast switching speed, and advanced paralleling capability.^[117]

Double-diffused metal–oxide–semiconductor (DMOS)[edit]

There are VDMOS (vertical double-diffused metal oxide semiconductor) and LDMOS (lateral double-diffused metal oxide semiconductor). Most power MOSFETs are made using this technology.

Insulated-gate bipolar transistor (IGBT)[edit]

The insulated-gate bipolar transistor (IGBT) is a power transistor with characteristics of both a MOSFET and bipolar junction transistor (BJT).^[118]

Multi-gate field-effect transistor (MuGFET)[edit]

The dual-gate MOSFET (DGMOS) has a tetrode configuration, where both gates control the current in the device. It is commonly used for small-signal devices in radio frequency applications where biasing the drain-side gate at constant potential reduces the gain loss caused by Miller effect, replacing two separate transistors in cascode configuration. Other common uses in RF circuits include gain control and mixing (frequency conversion). The tetrode description, though accurate, does not replicate the vacuum-tube tetrode. Vacuum-tube tetrodes, using a screen grid, exhibit much lower grid-plate capacitance and much higher output impedance and voltage gains than triode vacuum tubes. These improvements are commonly an order of magnitude (10 times) or considerably more. Tetrode transistors (whether bipolar junction or field-effect) do not exhibit improvements of such a great degree.

The FinFET is a double-gate silicon-on-insulator device, one of a number of geometries being introduced to mitigate the effects of short channels and reduce drain-induced barrier lowering. The fin refers to the narrow channel between source and drain. A thin insulating oxide layer on either side of the fin separates it from the gate. SOI FinFETs with a thick oxide on top of the fin are called double-gate and those with a thin oxide on top as well as on the sides are called triple-gate FinFETs.^[119][120]

A double-gate MOSFET transistor was first demonstrated in 1984 by Electrotechnical Laboratory researchers Toshihiro Sekigawa and Yutaka Hayashi.^[121][122] A GAAFET (gate-all-around MOSFET), a type of multi-gate non-planar 3D transistor, was first demonstrated in 1988 by a Toshiba research team including Fujio Masuoka, H. Takato and K. Sunouchi.^[123][124] The FinFET (fin field-effect transistor), a type of 3D non-planar double-gate MOSFET, originated from the research of Digh Hisamoto and his team at Hitachi Central Research Laboratory in 1989.^[125][126] The development of nanowire multi-gate MOSFETs have since become fundamental to nanoelectronics.^[127]

Radiation-hardened-by-design (RHBD)[edit]

Semiconductor sub-micrometer and nanometer electronic circuits are the primary concern for operating within the normal tolerance in harsh radiation environments like outer space. One of the design approaches for making a radiation-hardened-by-design (RHBD) device is enclosed-layout-transistor (ELT). Normally, the gate of the MOSFET surrounds the drain, which is placed in the center of the ELT. The source of the MOSFET surrounds the gate. Another RHBD MOSFET is called H-Gate. Both of these transistors have very low leakage current with respect to radiation. However, they are large in size and take more space on silicon than a standard MOSFET. In older STI (shallow trench isolation) designs, radiation strikes near the silicon oxide region cause the channel inversion at the corners of the standard MOSFET due to accumulation of radiation induced trapped charges. If the charges are large enough, the accumulated charges affect STI surface edges along the channel near the channel interface (gate) of the standard MOSFET. Thus the device channel inversion occurs along the channel edges and the device creates an off-state leakage path, causing the device to turn on. So the reliability of circuits degrades severely. The ELT offers many advantages. These advantages include improvement of reliability by reducing unwanted surface inversion at the gate edges that occurs in the standard MOSFET. Since the gate edges are enclosed in ELT, there is no gate oxide edge (STI at gate interface), and thus the transistor off-state leakage is reduced considerably. Low-power microelectronic circuits including computers, communication devices and monitoring systems in the space shuttle and satellites are very different to what is used on earth. They require radiation (high-speed atomic particles like proton and neutron, solar flare magnetic energy dissipation in Earth's space, energetic cosmic rays like X-ray, gamma ray etc.) tolerant circuits. These special electronics are designed by applying different techniques using RHBD MOSFETs to ensure safer journeys and space-walks for astronauts.

Applications[edit]

The MOSFET is by far the most widely used transistor in both digital circuits and analog circuits, and it is the backbone of modern electronics. A common use in analog circuits is the construction of differential amplifiers, used as input stages in op-amps, video amplifiers, high-speed comparators, and many other analog circuits.^[128]

Discrete MOSFET devices are widely used in applications such as switch mode power supplies, variable-frequency drives and other power electronics applications where each device may be switching thousands of watts. Radio-frequency amplifiers up to the UHF spectrum use MOSFET transistors as analog signal and power amplifiers. Radio systems also use MOSFETs as oscillators, or mixers to convert frequencies. MOSFET devices are also applied in audio-frequency power amplifiers for public address systems, sound reinforcement and home and automobile sound systems.^{[citation needed]}

MOS integrated circuits[edit]

Following the development of clean rooms to reduce contamination to levels never before thought necessary, and of photolithography^[129] and the planar process to allow circuits to be made in very few steps, the Si–SiO₂ system possessed the technical attractions of low cost of production (on a per circuit basis) and ease of integration. Largely because of these two factors, the MOSFET has become the most widely used type of transistor in integrated circuits (ICs), and it is the most critical device component in modern ICs.^[68]

Mohamed Atalla first proposed the concept of the MOS integrated circuit (MOS IC) in 1960, followed by Dawon Kahng in 1961, both noting that the MOS transistor's ease of fabrication made it useful for integrated circuits.^[14][20] The earliest experimental MOS IC to be demonstrated was a 16-transistor chip built by Fred Heiman and Steven Hofstein at RCA in 1962.^[7]General Microelectronics later introduced the first commercial MOS integrated circuits in 1964, consisting of 120 p-channel transistors.^[130] It was a 20-bit shift register, developed by Robert Norman^[7] and Frank Wanlass.^[131] In 1967, Bell Labs researchers Robert Kerwin, Donald Klein and John Sarace developed the self-aligned gate (silicon-gate) MOS transistor, which Fairchild Semiconductor researchers Federico Faggin and Tom Klein used to develop the first silicon-gate MOS IC.^[132]

Large-scale integration (LSI)[edit]

With its high scalability,^[3] and much lower power consumption and higher density than bipolar junction transistors,^[6] the MOSFET made it possible to build high-density ICs.^[1] MOS technology enabled the integration of more than 10,000 transistors in a single LSI (large-scale integration) chip by the early 1970s,^[133] and later very large-scale integration (VLSI).^[5][53]

One of the earliest influential consumer electronic products enabled by MOS LSI circuits was the electronic pocket calculator.^[133] In 1965, the Victor 3900 desktop calculator was the first MOS LSI calculator, with 29 MOS LSI chips.^[134] In 1967 the Texas Instruments Cal-Tech was the first prototype electronic handheld calculator, with three MOS LSI chips, and it was later released as the Canon Pocketronic in 1970.^[135] The Sharp QT-8D desktop calculator was the first mass-produced LSI MOS calculator in 1969,^[134] and the Sharp EL-8 which used four MOS LSI chips was the first commercial electronic handheld calculator in 1970.^[135] The first true electronic pocket calculator was the Busicom LE-120A HANDY LE, which used a single MOS LSI calculator-on-a-chip from Mostek, and was released in 1971.^[135]

By 1972, MOS LSI circuits were commercialized for numerous applications, including automobiles, trucks, home appliances, business machines, electronic musical instruments, computer peripherals, cash registers, calculators, data transmission and telecommunication equipment.^[136]

Microprocessors[edit]

The MOSFET is the basis of every microprocessor,^[35] and was responsible for the invention of the microprocessor.^[137] The earliest microprocessors were all MOS chips, built with MOS LSI circuits. The first multi-chip microprocessors, the Four-Phase Systems AL1 in 1969 and the Garrett AiResearchMP944 in 1970, were developed with multiple MOS LSI chips. The first commercial single-chip microprocessor, the Intel 4004, was developed by Federico Faggin, using his silicon-gate MOS IC technology, with Intel engineers Marcian Hoff and Stan Mazor, and Busicom engineer Masatoshi Shima.^[138] With the arrival of CMOS microprocessors in 1975, the term 'MOS microprocessors' began to refer to chips fabricated entirely from PMOS logic or fabricated entirely from NMOS logic, contrasted with 'CMOS microprocessors' and 'bipolar bit-slice processors'.^[139]

CMOS circuits[edit]

Digital[edit]

The growth of digital technologies like the microprocessor has provided the motivation to advance MOSFET technology faster than any other type of silicon-based transistor.^[140] A big advantage of MOSFETs for digital switching is that the oxide layer between the gate and the channel prevents DC current from flowing through the gate, further reducing power consumption and giving a very large input impedance. The insulating oxide between the gate and channel effectively isolates a MOSFET in one logic stage from earlier and later stages, which allows a single MOSFET output to drive a considerable number of MOSFET inputs. Bipolar transistor-based logic (such as TTL) does not have such a high fanout capacity. This isolation also makes it easier for the designers to ignore to some extent loading effects between logic stages independently. That extent is defined by the operating frequency: as frequencies increase, the input impedance of the MOSFETs decreases.

Igbt Driver Circuit Schematic

Analog[edit]

The MOSFET's advantages in digital circuits do not translate into supremacy in all analog circuits. The two types of circuit draw upon different features of transistor behavior. Digital circuits switch, spending most of their time either fully on or fully off. The transition from one to the other is only of concern with regards to speed and charge required. Analog circuits depend on operation in the transition region where small changes to V_gs can modulate the output (drain) current. The JFET and bipolar junction transistor (BJT) are preferred for accurate matching (of adjacent devices in integrated circuits), higher transconductance and certain temperature characteristics which simplify keeping performance predictable as circuit temperature varies.

Nevertheless, MOSFETs are widely used in many types of analog circuits because of their own advantages (zero gate current, high and adjustable output impedance and improved robustness vs. BJTs which can be permanently degraded by even lightly breaking down the emitter-base).^[vague] The characteristics and performance of many analog circuits can be scaled up or down by changing the sizes (length and width) of the MOSFETs used. By comparison, in bipolar transistors the size of the device does not significantly affect its performance.^{[citation needed]} MOSFETs' ideal characteristics regarding gate current (zero) and drain-source offset voltage (zero) also make them nearly ideal switch elements, and also make switched capacitor analog circuits practical. In their linear region, MOSFETs can be used as precision resistors, which can have a much higher controlled resistance than BJTs. In high power circuits, MOSFETs sometimes have the advantage of not suffering from thermal runaway as BJTs do.^[dubious] Also, MOSFETs can be configured to perform as capacitors and gyrator circuits which allow op-amps made from them to appear as inductors, thereby allowing all of the normal analog devices on a chip (except for diodes, which can be made smaller than a MOSFET anyway) to be built entirely out of MOSFETs. This means that complete analog circuits can be made on a silicon chip in a much smaller space and with simpler fabrication techniques. MOSFETS are ideally suited to switch inductive loads because of tolerance to inductive kickback.

Some ICs combine analog and digital MOSFET circuitry on a single mixed-signal integrated circuit, making the needed board space even smaller. This creates a need to isolate the analog circuits from the digital circuits on a chip level, leading to the use of isolation rings and silicon on insulator (SOI). Since MOSFETs require more space to handle a given amount of power than a BJT, fabrication processes can incorporate BJTs and MOSFETs into a single device. Mixed-transistor devices are called bi-FETs (bipolar FETs) if they contain just one BJT-FET and BiCMOS (bipolar-CMOS) if they contain complementary BJT-FETs. Such devices have the advantages of both insulated gates and higher current density.

In the late 1980s, Asad Abidi pioneered RF CMOS technology, which uses MOS VLSI circuits, while working at UCLA. This changed the way in which RF circuits were designed, away from discrete bipolar transistors and towards CMOS integrated circuits. As of 2008, the radio transceivers in all wireless networking devices and modern mobile phones are mass-produced as RF CMOS devices.^[141]

Analog switches[edit]

MOSFET analog switches use the MOSFET to pass analog signals when on, and as a high impedance when off. Signals flow in both directions across a MOSFET switch. In this application, the drain and source of a MOSFET exchange places depending on the relative voltages of the source/drain electrodes. The source is the more negative side for an N-MOS or the more positive side for a P-MOS. All of these switches are limited on what signals they can pass or stop by their gate-source, gate-drain and source–drain voltages; exceeding the voltage, current, or power limits will potentially damage the switch.

Single-type[edit]

This analog switch uses a four-terminal simple MOSFET of either P or N type.

In the case of an n-type switch, the body is connected to the most negative supply (usually GND) and the gate is used as the switch control. Whenever the gate voltage exceeds the source voltage by at least a threshold voltage, the MOSFET conducts. The higher the voltage, the more the MOSFET can conduct. An N-MOS switch passes all voltages less than V_gate − V_tn. When the switch is conducting, it typically operates in the linear (or ohmic) mode of operation, since the source and drain voltages will typically be nearly equal.

In the case of a P-MOS, the body is connected to the most positive voltage, and the gate is brought to a lower potential to turn the switch on. The P-MOS switch passes all voltages higher than V_gate − V_tp (threshold voltage V_tp is negative in the case of enhancement-mode P-MOS).

Dual-type (CMOS)[edit]

This 'complementary' or CMOS type of switch uses one P-MOS and one N-MOS FET to counteract the limitations of the single-type switch. The FETs have their drains and sources connected in parallel, the body of the P-MOS is connected to the high potential (V_DD) and the body of the N-MOS is connected to the low potential (gnd). To turn the switch on, the gate of the P-MOS is driven to the low potential and the gate of the N-MOS is driven to the high potential. For voltages between V_DD − V_tn and gnd − V_tp, both FETs conduct the signal; for voltages less than gnd − V_tp, the N-MOS conducts alone; and for voltages greater than V_DD − V_tn, the P-MOS conducts alone.

The voltage limits for this switch are the gate-source, gate-drain and source-drain voltage limits for both FETs. Also, the P-MOS is typically two to three times wider than the N-MOS, so the switch will be balanced for speed in the two directions.

Tri-state circuitry sometimes incorporates a CMOS MOSFET switch on its output to provide for a low-ohmic, full-range output when on, and a high-ohmic, mid-level signal when off.

Power electronics[edit]

Power MOSFETs[edit]

The power MOSFET is the most widely used power device in the world.^[117] Advantages over bipolar junction transistors in power electronics include MOSFETs not requiring a continuous flow of drive current to remain in the ON state, offering higher switching speeds, lower switching power losses, lower on-resistances, and reduced susceptibility to thermal runaway.^[142] The power MOSFET had an impact on power supplies, enabling higher operating frequencies, size and weight reduction, and increased volume production.^[143]

MOSFETs are commonly used in switched-mode power supplies (SMPS)^[142] and DC-to-DC converters.^[144] Other common applications include portable information appliances, power integrated circuits, cell phones, notebook computers, Internetcommunications infrastructure,^[65]computer power supplies, television receiver circuits, home entertainment equipment, industrial technology, instrumentation and test gear applications,^[145]cellularwireless networks, consumer electronics, digital television, digital cameras, mobile computers,^[146]3D printers, LED lighting, battery-powered applications (such as for notebook and desktop computers), audio amplifiers, power amplifiers, telecommunications, television systems, radar systems, and military communications, among other uses.^[147]

Switching power supplies are the most common applications for power MOSFETs, which are also widely used for pulsedDC motor drives and Class Daudio amplifiers.^[148] MOSFETs are also the most widely used RF power amplifiers.^[38] MOSFET-based RF power amplifiers enabled the transition of mobile networks from analog to digital in the 1990s, leading to the wide proliferation of wireless mobile networks, which revolutionised telecommunication systems.^[38] The LDMOS in particular is the most widely used power amplifier in mobile networks, such as 2G, 3G,^[38] and 4G.^[39]Over 50billion discrete power MOSFETs are shipped annually as of 2018. They are widely used for automotive, industrial and communications systems in particular.^[149] Power MOSFETs are commonly used in automotive electronics, particularly as switching devices in electronic control units.^[150] The insulated-gate bipolar transistor (IGBT), a hybrid MOS-bipolar transistor, is also used for applications such as household appliances, cars, solar panels, fluorescent lighting, medical equipment, and bullet trains.^[151]

Space research[edit]

MOSFET devices were adopted by NASA for space research in 1964, for its Interplanetary Monitoring Platform (IMP) program.^[152] The use of MOSFETs was a major step forward in spacecraft electronics design. Data gathered by IMP spacecraft and satellites were used to support the Apollo program, enabling the first manned Moon landing with the Apollo 11 mission in 1969.^[153]

The Cassini–Huygens mission to Saturn in 1997 had power distribution accomplished 192 solid-statepower switches (SSPS), which also functioned as circuit breakers in the event of an overload condition. The switches were developed from a combination of two semiconductor devices with switching capabilities: the MOSFET and the ASIC (application-specific integrated circuit). This combination resulted in advanced power switches that had better performance characteristics than traditional mechanical switches.^[154]

Mosfet Application Circuits 2017

MOS memory[edit]

The first modern memory cells for computer memory was introduced in 1965, when John Schmidt at Fairchild Semiconductor designed the first MOS semiconductor memory, a 64-bit MOS SRAM (static random-access memory).^[155] SRAM became an alternative to magnetic-core memory, but required six MOS transistors for each bit of data.^[156]

MOS technology is the basis for DRAM (dynamic random-access memory). In 1966, Dr. Robert H. Dennard at the IBMThomas J. Watson Research Center was working on MOS memory. While examining the characteristics of MOS technology, he found it was capable of building capacitors, and that storing a charge or no charge on the MOS capacitor could represent the 1 and 0 of a bit, while the MOS transistor could control writing the charge to the capacitor. This led to his development of a single-transistor DRAM memory cell.^[156] In 1967, Dennard filed a patent under IBM for a single-transistor DRAM (dynamic random-access memory) memory cell, based on MOS technology.^[157] MOS memory enabled higher performance, was cheaper, and consumed less power, than magnetic-core memory, leading to MOS memory overtaking magnetic core memory as the dominant computer memory technology by the early 1970s.^[158]

Frank Wanlass, while studying MOSFET structures in 1963, noted the movement of charge through oxide onto a gate. While he did not pursue it, this idea would later become the basis for EPROM (erasable programmable read-only memory) technology.^[159] In 1967, Dawon Kahng and Simon Sze proposed that floating-gate memory cells, consisting of floating-gate MOSFETs (FGMOS), could be used to produce reprogrammable ROM (read-only memory).^[160] Floating-gate memory cells later became the basis for non-volatile memory (NVM) technologies including EPROM, EEPROM (electrically erasable programmable ROM) and flash memory.^[161]

Quantum physics[edit]

The MOSFET enables physicists to study electron behavior in a two-dimensional gas. In a MOSFET, conduction electrons travel in a thin surface layer, and a 'gate' voltage controls the number of charge carriers in this layer. This allows researchers to explore quantum effects by operating high-purity MOSFETs at liquid helium temperatures.^[71]

In 1978, the Gakushuin University researchers Jun-ichi Wakabayashi and Shinji Kawaji observed the Hall effect in experiments carried out on the inversion layer of MOSFETs.^[162] In 1980, Klaus von Klitzing, working at the high magnetic field laboratory in Grenoble with silicon-based MOSFET samples developed by Michael Pepper and Gerhard Dorda, made the unexpected discovery of the quantum Hall effect.^[71][163]

Image sensors[edit]

MOS capacitors are the basis for image sensors, including the charge-coupled device (CCD) and the CMOS active-pixel sensor, used in digital imaging and digital cameras.^[72]Willard Boyle and George E. Smith developed the CCD in 1969. While researching the MOS process, they realized that an electric charge was the analogy of the magnetic bubble and that it could be stored on a tiny MOS capacitor. As it was fairly straighforward to fabricate a series of MOS capacitors in a row, they connected a suitable voltage to them so that the charge could be stepped along from one to the next.^[72] The CCD is a semiconductor circuit that was later used in the first digital video cameras for television broadcasting.^[164]

The MOS active pixel sensor (APS) was developed by Tsutomu Nakamura at Olympus in 1985.^[165] The CMOS active pixel sensor (CMOS sensor) was later developed by Eric Fossum and his team in the early 1990s.^[166]

Construction[edit]

Gate material[edit]

The primary criterion for the gate material is that it is a good conductor. Highly doped polycrystalline silicon is an acceptable but certainly not ideal conductor, and also suffers from some more technical deficiencies in its role as the standard gate material. Nevertheless, there are several reasons favoring use of polysilicon:

1. The threshold voltage (and consequently the drain to source on-current) is modified by the work function difference between the gate material and channel material. Because polysilicon is a semiconductor, its work function can be modulated by adjusting the type and level of doping. Furthermore, because polysilicon has the same bandgap as the underlying silicon channel, it is quite straightforward to tune the work function to achieve low threshold voltages for both NMOS and PMOS devices. By contrast, the work functions of metals are not easily modulated, so tuning the work function to obtain low threshold voltages (LVT) becomes a significant challenge. Additionally, obtaining low-threshold devices on both PMOS and NMOS devices sometimes requires the use of different metals for each device type. While bimetallic integrated circuits (i.e., one type of metal for gate electrodes of NFETS and a second type of metal for gate electrodes of PFETS) are not common, they are known in patent literature and provide some benefit in terms of tuning electrical circuits' overall electrical performance.
2. The silicon-SiO₂ interface has been well studied and is known to have relatively few defects. By contrast many metal-insulator interfaces contain significant levels of defects which can lead to Fermi level pinning, charging, or other phenomena that ultimately degrade device performance.
3. In the MOSFET IC fabrication process, it is preferable to deposit the gate material prior to certain high-temperature steps in order to make better-performing transistors. Such high temperature steps would melt some metals, limiting the types of metal that can be used in a metal-gate-based process.

While polysilicon gates have been the de facto standard for the last twenty years, they do have some disadvantages which have led to their likely future replacement by metal gates. These disadvantages include:

• Polysilicon is not a great conductor (approximately 1000 times more resistive than metals) which reduces the signal propagation speed through the material. The resistivity can be lowered by increasing the level of doping, but even highly doped polysilicon is not as conductive as most metals. To improve conductivity further, sometimes a high-temperature metal such as tungsten, titanium, cobalt, and more recently nickel is alloyed with the top layers of the polysilicon. Such a blended material is called silicide. The silicide-polysilicon combination has better electrical properties than polysilicon alone and still does not melt in subsequent processing. Also the threshold voltage is not significantly higher than with polysilicon alone, because the silicide material is not near the channel. The process in which silicide is formed on both the gate electrode and the source and drain regions is sometimes called salicide, self-aligned silicide.
• When the transistors are extremely scaled down, it is necessary to make the gate dielectric layer very thin, around 1 nm in state-of-the-art technologies. A phenomenon observed here is the so-called poly depletion, where a depletion layer is formed in the gate polysilicon layer next to the gate dielectric when the transistor is in the inversion. To avoid this problem, a metal gate is desired. A variety of metal gates such as tantalum, tungsten, tantalum nitride, and titanium nitride are used, usually in conjunction with high-κ dielectrics. An alternative is to use fully silicided polysilicon gates, a process known as FUSI.

Present high performance CPUs use metal gate technology, together with high-κ dielectrics, a combination known as high-κ, metal gate (HKMG). The disadvantages of metal gates are overcome by a few techniques:^[167]

1. The threshold voltage is tuned by including a thin 'work function metal' layer between the high-κ dielectric and the main metal. This layer is thin enough that the total work function of the gate is influenced by both the main metal and thin metal work functions (either due to alloying during annealing, or simply due to the incomplete screening by the thin metal). The threshold voltage thus can be tuned by the thickness of the thin metal layer.
2. High-κ dielectrics are now well studied, and their defects are understood.
3. HKMG processes exist that do not require the metals to experience high temperature anneals; other processes select metals that can survive the annealing step.

Insulator[edit]

As devices are made smaller, insulating layers are made thinner, often through steps of thermal oxidation or localised oxidation of silicon (LOCOS). For nano-scaled devices, at some point tunneling of carriers through the insulator from the channel to the gate electrode takes place. To reduce the resulting leakage current, the insulator can be made thinner by choosing a material with a higher dielectric constant. To see how thickness and dielectric constant are related, note that Gauss's law connects field to charge as:

${\displaystyle Q=\kappa {ϵ}_{0}E,}$

with Q = charge density, κ = dielectric constant, ε₀ = permittivity of empty space and E = electric field. From this law it appears the same charge can be maintained in the channel at a lower field provided κ is increased. The voltage on the gate is given by:

${\displaystyle V_{\text{G}}=V_{\text{ch}}+E{t}_{\text{ins}}=V_{\text{ch}}+\frac{Q{t}_{\text{ins}}}{\kappa {ϵ}_0},}$

with V_G = gate voltage, V_ch = voltage at channel side of insulator, and t_ins = insulator thickness. This equation shows the gate voltage will not increase when the insulator thickness increases, provided κ increases to keep t_ins / κ = constant (see the article on high-κ dielectrics for more detail, and the section in this article on gate-oxide leakage).

The insulator in a MOSFET is a dielectric which can in any event be silicon oxide, formed by LOCOS but many other dielectric materials are employed. The generic term for the dielectric is gate dielectric since the dielectric lies directly below the gate electrode and above the channel of the MOSFET.

Junction design[edit]

Mosfet

The source-to-body and drain-to-body junctions are the object of much attention because of three major factors: their design affects the current-voltage (I-V) characteristics of the device, lowering output resistance, and also the speed of the device through the loading effect of the junction capacitances, and finally, the component of stand-by power dissipation due to junction leakage.

The drain induced barrier lowering of the threshold voltage and channel length modulation effects upon I-V curves are reduced by using shallow junction extensions. In addition, halo doping can be used, that is, the addition of very thin heavily doped regions of the same doping type as the body tight against the junction walls to limit the extent of depletion regions.^[168]

The capacitive effects are limited by using raised source and drain geometries that make most of the contact area border thick dielectric instead of silicon.^[169]

These various features of junction design are shown (with artistic license) in the figure.

Scaling[edit]

Over the past decades, the MOSFET (as used for digital logic) has continually been scaled down in size; typical MOSFET channel lengths were once several micrometres, but modern integrated circuits are incorporating MOSFETs with channel lengths of tens of nanometers. Robert Dennard's work on scaling theory was pivotal in recognising that this ongoing reduction was possible. The semiconductor industry maintains a 'roadmap', the ITRS,^[170] which sets the pace for MOSFET development. Historically, the difficulties with decreasing the size of the MOSFET have been associated with the semiconductor device fabrication process, the need to use very low voltages, and with poorer electrical performance necessitating circuit redesign and innovation (small MOSFETs exhibit higher leakage currents and lower output resistance). As of 2019, the smallest MOSFETs in production are 5 nmFinFETsemiconductor nodes, manufactured by Samsung Electronics and TSMC.^[171][172]

Smaller MOSFETs are desirable for several reasons. The main reason to make transistors smaller is to pack more and more devices in a given chip area. This results in a chip with the same functionality in a smaller area, or chips with more functionality in the same area. Since fabrication costs for a semiconductor wafer are relatively fixed, the cost per integrated circuits is mainly related to the number of chips that can be produced per wafer. Hence, smaller ICs allow more chips per wafer, reducing the price per chip. In fact, over the past 30 years the number of transistors per chip has been doubled every 2–3 years once a new technology node is introduced. For example, the number of MOSFETs in a microprocessor fabricated in a 45 nm technology can well be twice as many as in a 65 nm chip. This doubling of transistor density was first observed by Gordon Moore in 1965 and is commonly referred to as Moore's law.^[173] It is also expected that smaller transistors switch faster. For example, one approach to size reduction is a scaling of the MOSFET that requires all device dimensions to reduce proportionally. The main device dimensions are the channel length, channel width, and oxide thickness. When they are scaled down by equal factors, the transistor channel resistance does not change, while gate capacitance is cut by that factor. Hence, the RC delay of the transistor scales with a similar factor. While this has been traditionally the case for the older technologies, for the state-of-the-art MOSFETs reduction of the transistor dimensions does not necessarily translate to higher chip speed because the delay due to interconnections is more significant.

Producing MOSFETs with channel lengths much smaller than a micrometre is a challenge, and the difficulties of semiconductor device fabrication are always a limiting factor in advancing integrated circuit technology. Though processes such as ALD have improved fabrication for small components, the small size of the MOSFET (less than a few tens of nanometers) has created operational problems:

Higher subthreshold conduction

As MOSFET geometries shrink, the voltage that can be applied to the gate must be reduced to maintain reliability. To maintain performance, the threshold voltage of the MOSFET has to be reduced as well. As threshold voltage is reduced, the transistor cannot be switched from complete turn-off to complete turn-on with the limited voltage swing available; the circuit design is a compromise between strong current in the on case and low current in the off case, and the application determines whether to favor one over the other. Subthreshold leakage (including subthreshold conduction, gate-oxide leakage and reverse-biased junction leakage), which was ignored in the past, now can consume upwards of half of the total power consumption of modern high-performance VLSI chips.^[174][175]

Increased gate-oxide leakage

The gate oxide, which serves as insulator between the gate and channel, should be made as thin as possible to increase the channel conductivity and performance when the transistor is on and to reduce subthreshold leakage when the transistor is off. However, with current gate oxides with a thickness of around 1.2 nm (which in silicon is ~5 atoms thick) the quantum mechanical phenomenon of electron tunneling occurs between the gate and channel, leading to increased power consumption. Silicon dioxide has traditionally been used as the gate insulator. Silicon dioxide however has a modest dielectric constant. Increasing the dielectric constant of the gate dielectric allows a thicker layer while maintaining a high capacitance (capacitance is proportional to dielectric constant and inversely proportional to dielectric thickness). All else equal, a higher dielectric thickness reduces the quantum tunneling current through the dielectric between the gate and the channel. Insulators that have a larger dielectric constant than silicon dioxide (referred to as high-κ dielectrics), such as group IVb metal silicates e.g. hafnium and zirconium silicates and oxides are being used to reduce the gate leakage from the 45 nanometer technology node onwards. On the other hand, the barrier height of the new gate insulator is an important consideration; the difference in conduction band energy between the semiconductor and the dielectric (and the corresponding difference in valence band energy) also affects leakage current level. For the traditional gate oxide, silicon dioxide, the former barrier is approximately 8 eV. For many alternative dielectrics the value is significantly lower, tending to increase the tunneling current, somewhat negating the advantage of higher dielectric constant. The maximum gate-source voltage is determined by the strength of the electric field able to be sustained by the gate dielectric before significant leakage occurs. As the insulating dielectric is made thinner, the electric field strength within it goes up for a fixed voltage. This necessitates using lower voltages with the thinner dielectric.

Increased junction leakage

To make devices smaller, junction design has become more complex, leading to higher doping levels, shallower junctions, 'halo' doping and so forth,^[176][177] all to decrease drain-induced barrier lowering (see the section on junction design). To keep these complex junctions in place, the annealing steps formerly used to remove damage and electrically active defects must be curtailed^[178] increasing junction leakage. Heavier doping is also associated with thinner depletion layers and more recombination centers that result in increased leakage current, even without lattice damage.

Drain-induced barrier lowering (DIBL) and V_T roll off

Because of the short-channel effect, channel formation is not entirely done by the gate, but now the drain and source also affect the channel formation. As the channel length decreases, the depletion regions of the source and drain come closer together and make the threshold voltage (V_T) a function of the length of the channel. This is called V_T roll-off. V_T also becomes function of drain to source voltage V_DS. As we increase the V_DS, the depletion regions increase in size, and a considerable amount of charge is depleted by the V_DS. The gate voltage required to form the channel is then lowered, and thus, the V_T decreases with an increase in V_DS. This effect is called drain induced barrier lowering (DIBL).

Lower output resistance

For analog operation, good gain requires a high MOSFET output impedance, which is to say, the MOSFET current should vary only slightly with the applied drain-to-source voltage. As devices are made smaller, the influence of the drain competes more successfully with that of the gate due to the growing proximity of these two electrodes, increasing the sensitivity of the MOSFET current to the drain voltage. To counteract the resulting decrease in output resistance, circuits are made more complex, either by requiring more devices, for example the cascode and cascade amplifiers, or by feedback circuitry using operational amplifiers, for example a circuit like that in the adjacent figure.

Lower transconductance

The transconductance of the MOSFET decides its gain and is proportional to hole or electron mobility (depending on device type), at least for low drain voltages. As MOSFET size is reduced, the fields in the channel increase and the dopant impurity levels increase. Both changes reduce the carrier mobility, and hence the transconductance. As channel lengths are reduced without proportional reduction in drain voltage, raising the electric field in the channel, the result is velocity saturation of the carriers, limiting the current and the transconductance.

Interconnect capacitance

Traditionally, switching time was roughly proportional to the gate capacitance of gates. However, with transistors becoming smaller and more transistors being placed on the chip, interconnect capacitance (the capacitance of the metal-layer connections between different parts of the chip) is becoming a large percentage of capacitance.^[179][180] Signals have to travel through the interconnect, which leads to increased delay and lower performance.

Heat production

The ever-increasing density of MOSFETs on an integrated circuit creates problems of substantial localized heat generation that can impair circuit operation. Circuits operate more slowly at high temperatures, and have reduced reliability and shorter lifetimes. Heat sinks and other cooling devices and methods are now required for many integrated circuits including microprocessors. Power MOSFETs are at risk of thermal runaway. As their on-state resistance rises with temperature, if the load is approximately a constant-current load then the power loss rises correspondingly, generating further heat. When the heatsink is not able to keep the temperature low enough, the junction temperature may rise quickly and uncontrollably, resulting in destruction of the device.

Process variations

With MOSFETs becoming smaller, the number of atoms in the silicon that produce many of the transistor's properties is becoming fewer, with the result that control of dopant numbers and placement is more erratic. During chip manufacturing, random process variations affect all transistor dimensions: length, width, junction depths, oxide thickness etc., and become a greater percentage of overall transistor size as the transistor shrinks. The transistor characteristics become less certain, more statistical. The random nature of manufacture means we do not know which particular example MOSFETs actually will end up in a particular instance of the circuit. This uncertainty forces a less optimal design because the design must work for a great variety of possible component MOSFETs. See process variation, design for manufacturability, reliability engineering, and statistical process control.^[181]

Modeling challenges

Modern ICs are computer-simulated with the goal of obtaining working circuits from the very first manufactured lot. As devices are miniaturized, the complexity of the processing makes it difficult to predict exactly what the final devices look like, and modeling of physical processes becomes more challenging as well. In addition, microscopic variations in structure due simply to the probabilistic nature of atomic processes require statistical (not just deterministic) predictions. These factors combine to make adequate simulation and 'right the first time' manufacture difficult.

Timeline[edit]

PMOS and NMOS[edit]

Mosfet Application Note

CMOS (single-gate)[edit]

Multi-gate MOSFET (MuGFET)[edit]

Other types of MOSFET[edit]

See also[edit]

References[edit]

1. ^ ^abc'Who Invented the Transistor?'. Computer History Museum. 4 December 2013. Retrieved 20 July 2019.
2. ^Bakshi, U. A.; Godse, A. P. (2007). '§8.2 The depletion mode MOSFET'. Electronic Circuits. Technical Publications. pp. 8–2. ISBN978-81-8431-284-3.
3. ^ ^abMotoyoshi, M. (2009). 'Through-Silicon Via (TSV)'(PDF). Proceedings of the IEEE. 97 (1): 43–48. doi:10.1109/JPROC.2008.2007462. ISSN0018-9219.
4. ^Lécuyer, Christophe (2006). Making Silicon Valley: Innovation and the Growth of High Tech, 1930-1970. Chemical Heritage Foundation. p. 273. ISBN9780262122818.
5. ^ ^abcSze, Simon Min. 'Metal-oxide-semiconductor field-effect transistors'. Encyclopedia Britannica. Retrieved 21 July 2019.
6. ^ ^ab'Transistors Keep Moore's Law Alive'. EETimes. 12 December 2018. Retrieved 18 July 2019.
7. ^ ^abc'Tortoise of Transistors Wins the Race - CHM Revolution'. Computer History Museum. Retrieved 22 July 2019.
8. ^Lilienfeld, Julius Edgar (1926-10-08) 'Method and apparatus for controlling electric currents' U.S. Patent 1,745,175A
9. ^ ^abcde'Dawon Kahng'. National Inventors Hall of Fame. Retrieved 27 June 2019.
10. ^ ^abcdef'1960: Metal Oxide Semiconductor (MOS) Transistor Demonstrated'. The Silicon Engine: A Timeline of Semiconductors in Computers. Computer History Museum. Retrieved August 31, 2019.
11. ^Lee, Thomas H. (2003). The Design of CMOS Radio-Frequency Integrated Circuits(PDF). Cambridge University Press. ISBN9781139643771.
12. ^ ^abcPuers, Robert; Baldi, Livio; Voorde, Marcel Van de; Nooten, Sebastiaan E. van (2017). Nanoelectronics: Materials, Devices, Applications, 2 Volumes. John Wiley & Sons. p. 14. ISBN9783527340538.
13. ^ ^abDeal, Bruce E. (1998). 'Highlights Of Silicon Thermal Oxidation Technology'. Silicon materials science and technology. The Electrochemical Society. p. 183. ISBN9781566771931.
14. ^ ^abcdMoskowitz, Sanford L. (2016). Advanced Materials Innovation: Managing Global Technology in the 21st century. John Wiley & Sons. pp. 165–167. ISBN9780470508923.
15. ^ ^abcd'Martin (John) M. Atalla'. National Inventors Hall of Fame. 2009. Retrieved 21 June 2013.
16. ^ ^abcdefgLojek, Bo (2007). History of Semiconductor Engineering. Springer Science & Business Media. pp. 321–3. ISBN9783540342588.
17. ^Huff, Howard (2005). High Dielectric Constant Materials: VLSI MOSFET Applications. Springer Science & Business Media. p. 34. ISBN9783540210818.
18. ^Lojek, Bo (2007). History of Semiconductor Engineering. Springer Science & Business Media. p. 120. ISBN9783540342588.
19. ^U.S. Patent 2,953,486
20. ^ ^abBassett, Ross Knox (2007). To the Digital Age: Research Labs, Start-up Companies, and the Rise of MOS Technology. Johns Hopkins University Press. p. 22. ISBN9780801886393.
21. ^Atalla, M.; Kahng, D. (1960). 'Silicon–silicon dioxide field induced surface devices'. IRE-AIEE Solid State Device Research Conference. Carnegie Mellon University Press.
22. ^'Oral-History: Goldey, Hittinger and Tanenbaum'. Institute of Electrical and Electronics Engineers. 25 September 2008. Retrieved 22 August 2019.
23. ^U.S. Patent 3,206,670 (1960)
24. ^U.S. Patent 3,102,230 (1960)
25. ^'1948 – Conception of the Junction Transistor'. The Silicon Engine: A Timeline of Semiconductors in Computers. Computer History Museum. 2007.
26. ^Bassett, Ross Knox (2007). To the Digital Age: Research Labs, Start-up Companies, and the Rise of MOS Technology. JHU Press. pp. 42 & 332. ISBN9780801886393.
27. ^Sah, Chih-Tang (October 1988). 'Evolution of the MOS transistor-from conception to VLSI'(PDF). Proceedings of the IEEE. 76 (10): 1280–1326 (1290). doi:10.1109/5.16328. ISSN0018-9219. Those of us active in silicon material and device research during 1956–1960 considered this successful effort by the Bell Labs group led by Atalla to stabilize the silicon surface the most important and significant technology advance, which blazed the trail that led to silicon integrated circuit technology developments in the second phase and volume production in the third phase.
28. ^Sah, C. T. (November 1961). 'A New Semiconductor Tetrode-The Surface-Potential Controlled Transistor'. Proceedings of the IRE. 49 (11): 1623–1634. doi:10.1109/JRPROC.1961.287763.
29. ^Lécuyer, Christophe (2006). Making Silicon Valley: Innovation and the Growth of High Tech, 1930-1970. Chemical Heritage Foundation. pp. 253–6 & 273. ISBN9780262122818.
30. ^'60s Trends in the Semiconductor Industry'. Semiconductor History Museum of Japan. Retrieved 7 August 2019.
31. ^McCluskey, Matthew D.; Haller, Eugene E. (2012). Dopants and Defects in Semiconductors. CRC Press. p. 3. ISBN9781439831533.
32. ^Daniels, Lee A. (28 May 1992). 'Dr. Dawon Kahng, 61, Inventor In Field of Solid-State Electronics'. The New York Times. Retrieved 1 April 2017.
33. ^Golio, Mike; Golio, Janet (2018). RF and Microwave Passive and Active Technologies. CRC Press. pp. 18–2. ISBN9781420006728.
34. ^ ^abc'Remarks by Director Iancu at the 2019 International Intellectual Property Conference'. United States Patent and Trademark Office. June 10, 2019. Retrieved 20 July 2019.
35. ^ ^abcColinge, Jean-Pierre; Greer, James C. (2016). Nanowire Transistors: Physics of Devices and Materials in One Dimension. Cambridge University Press. p. 2. ISBN9781107052406.
36. ^Memories: A Personal History of Bell Telephone Laboratories(PDF). Institute of Electrical and Electronics Engineers. 2011. p. 59. ISBN1463677979.
37. ^ ^abcKimizuka, Noboru; Yamazaki, Shunpei (2016). Physics and Technology of Crystalline Oxide Semiconductor CAAC-IGZO: Fundamentals. John Wiley & Sons. p. 217. ISBN9781119247401.
38. ^ ^abcdeBaliga, B. Jayant (2005). Silicon RF Power MOSFETS. World Scientific. ISBN9789812561213.
39. ^ ^abcdAsif, Saad (2018). 5G Mobile Communications: Concepts and Technologies. CRC Press. pp. 128–134. ISBN9780429881343.
40. ^'MOSFET: Toward the Scaling Limit'. Semiconductor Technology Online. Retrieved 29 July 2019.
41. ^Colinge, Jean-Pierre; Greer, Jim (2010). 'Chapter 12: Transistor Structures for Nanoelectronics'. Handbook of Nanophysics: Nanoelectronics and Nanophotonics. CRC Press. p. 12-1. ISBN9781420075519.
42. ^Chan, Yi-Jen (1992). Studies of InAIAs/InGaAs and GaInP/GaAs heterostructure FET's for high speed applications. University of Michigan. p. 1. The Si MOSFET has revolutionized the electronics industry and as a result impacts our daily lives in almost every conceivable way.
43. ^Ashley, Kenneth L. (2002). Analog Electronics with LabVIEW. Prentice Hall Professional. p. 10. ISBN9780130470652.
44. ^Frank, D. J.; Dennard, R. H.; Nowak, E.; Solomon, P. M.; Taur, Y. (2001). 'Device scaling limits of Si MOSFETs and their application dependencies'. Proceedings of the IEEE. 89 (3): 259–288. doi:10.1109/5.915374. ISSN0018-9219.
45. ^Klimecky, Pete Ivan (2002). Plasma density control for reactive ion etch variation reduction in industrial microelectronics. University of Michigan. p. 2. Arguably the most important device breakthrough for the computing industry, however, occurred in 1960 when Kahng and Atalla proposed and fabricated the first metal-oxide-semiconductor field-effect-transistor, or MOSFET, using a thermally oxidized silicon structure.
46. ^Deal, Bruce E. (1988). 'The Thermal Oxidation of Silicon and Other Semiconductor Materials'. Semiconductor Materials and Process Technology Handbook: For Very Large Scale Integration (VLSI) and Ultra Large Scale Integration (ULSI)(PDF). Noyes Publications. p. 46. ISBN9780815511502.
47. ^Kubozono, Yoshihiro; He, Xuexia; Hamao, Shino; Uesugi, Eri; Shimo, Yuma; Mikami, Takahiro; Goto, Hidenori; Kambe, Takashi (2015). 'Application of Organic Semiconductors toward Transistors'. Nanodevices for Photonics and Electronics: Advances and Applications. CRC Press. p. 355. ISBN9789814613750.
48. ^Thompson, S. E.; Chau, R. S.; Ghani, T.; Mistry, K.; Tyagi, S.; Bohr, M. T. (2005). 'In search of 'Forever,' continued transistor scaling one new material at a time'. IEEE Transactions on Semiconductor Manufacturing. 18 (1): 26–36. doi:10.1109/TSM.2004.841816. ISSN0894-6507. In the field of electronics, the planar Si metal–oxide–semiconductor field-effect transistor (MOSFET) is perhaps the most important invention.
49. ^ ^ab'13 Sextillion & Counting: The Long & Winding Road to the Most Frequently Manufactured Human Artifact in History'. Computer History Museum. April 2, 2018. Retrieved 28 July 2019.
50. ^Baker, R. Jacob (2011). CMOS: Circuit Design, Layout, and Simulation. John Wiley & Sons. p. 7. ISBN978-1118038239.
51. ^Maloberti, Franco; Davies, Anthony C. (2016). A Short History of Circuits and Systems: From Green, Mobile, Pervasive Networking to Big Data Computing(PDF). IEEE Circuits and Systems Society. pp. 65–6. ISBN9788793609860.
52. ^'Rethink Power Density with GaN'. Electronic Design. 21 April 2017. Retrieved 23 July 2019.
53. ^ ^abGrant, Duncan Andrew; Gowar, John (1989). Power MOSFETS: theory and applications. Wiley. p. 1. ISBN9780471828679. The metal-oxide-semiconductor field-effect transistor (MOSFET) is the most commonly used active device in the very large-scale integration of digital integrated circuits (VLSI). During the 1970s these components revolutionized electronic signal processing, control systems and computers.
54. ^Williams, J. B. (2017). The Electronics Revolution: Inventing the Future. Springer. p. 75. ISBN9783319490885. Though these devices were not of great interest at the time, it was to be these Metal Oxide Semiconductor MOS devices that were going to have enormous impact in the future
55. ^Zimbovskaya, Natalya A. (2013). Transport Properties of Molecular Junctions. Springer. p. 231. ISBN9781461480112.
56. ^ ^abcFeldman, Leonard C. (2001). 'Introduction'. Fundamental Aspects of Silicon Oxidation. Springer Science & Business Media. pp. 1–11. ISBN9783540416821.
57. ^ ^abDabrowski, Jarek; Müssig, Hans-Joachim (2000). '1.2. The Silicon Age'. Silicon Surfaces and Formation of Interfaces: Basic Science in the Industrial World. World Scientific. pp. 3–13. ISBN9789810232863.
58. ^Malmstadt, Howard V.; Enke, Christie G.; Crouch, Stanley R. (1994). Making the Right Connections: Microcomputers and Electronic Instrumentation. American Chemical Society. p. 389. ISBN9780841228610. The relative simplicity and low power requirements of MOSFETs have fostered today's microcomputer revolution.
59. ^ ^ab'The Foundation of Today's Digital World: The Triumph of the MOS Transistor'. Computer History Museum. 13 July 2010. Retrieved 21 July 2019.
60. ^Raymer, Michael G. (2009). The Silicon Web: Physics for the Internet Age. CRC Press. p. 365. ISBN9781439803127.
61. ^Wong, Kit Po (2009). Electrical Engineering - Volume II. EOLSS Publications. p. 7. ISBN9781905839780.
62. ^'Transistors - an overview'. ScienceDirect. Retrieved 8 August 2019.
63. ^Fossum, Jerry G.; Trivedi, Vishal P. (2013). Fundamentals of Ultra-Thin-Body MOSFETs and FinFETs. Cambridge University Press. p. vii. ISBN9781107434493.
64. ^Franco, Jacopo; Kaczer, Ben; Groeseneken, Guido (2013). Reliability of High Mobility SiGe Channel MOSFETs for Future CMOS Applications. Springer Science & Business Media. pp. 1–2. ISBN9789400776630.
65. ^ ^abWhiteley, Carol; McLaughlin, John Robert (2002). Technology, Entrepreneurs, and Silicon Valley. Institute for the History of Technology. ISBN9780964921719. These active electronic components, or power semiconductor products, from Siliconix are used to switch and convert power in a wide range of systems, from portable information appliances to the communications infrastructure that enables the Internet. The company's power MOSFETs — tiny solid-state switches, or metal oxide semiconductor field-effect transistors — and power integrated circuits are widely used in cell phones and notebook computers to manage battery power efficiently
66. ^Omura, Yasuhisa; Mallik, Abhijit; Matsuo, Naoto (2017). MOS Devices for Low-Voltage and Low-Energy Applications. John Wiley & Sons. p. 53. ISBN9781119107354.
67. ^Jindal, R. P. (2009). 'From millibits to terabits per second and beyond - Over 60 years of innovation'. 2009 2nd International Workshop on Electron Devices and Semiconductor Technology: 1–6. doi:10.1109/EDST.2009.5166093.
68. ^ ^abcKuo, Yue (1 January 2013). 'Thin Film Transistor Technology—Past, Present, and Future'(PDF). The Electrochemical Society Interface. 22 (1): 55–61. doi:10.1149/2.F06131if. ISSN1064-8208.
69. ^Kuo, Y. (2008). Thin Film Transistors 9 (TFT 9). The Electrochemical Society. p. 365. ISBN9781566776554.
70. ^'Milestones:List of IEEE Milestones'. Institute of Electrical and Electronics Engineers. Retrieved 25 July 2019.
71. ^ ^abcLindley, David (15 May 2015). 'Focus: Landmarks—Accidental Discovery Leads to Calibration Standard'. Physics. 8.
72. ^ ^abcWilliams, J. B. (2017). The Electronics Revolution: Inventing the Future. Springer. pp. 245 & 249. ISBN9783319490885.
73. ^Woodall, Jerry M. (2010). Fundamentals of III-V Semiconductor MOSFETs. Springer Science & Business Media. p. 2. ISBN9781441915474.
74. ^'Advanced information on the Nobel Prize in Physics 2000'(PDF). Nobel Prize. June 2018. Retrieved 17 August 2019.
75. ^'Intel 45nm Hi-k Silicon Technology'. Archived from the original on October 6, 2009.
76. ^'memory components data book'(PDF). memory components data book. Intel. pp. 2–1. Archived from the original(PDF) on 4 March 2016. Retrieved 30 August 2015.
77. ^'Using a MOSFET as a Switch'. 090507 brunningsoftware.co.uk
78. ^Shichman, H. & Hodges, D. A. (1968). 'Modeling and simulation of insulated-gate field-effect transistor switching circuits'. IEEE Journal of Solid-State Circuits. SC-3 (3): 285–289. Bibcode:1968IJSSC...3..285S. doi:10.1109/JSSC.1968.1049902.
79. ^For example, see Cheng, Yuhua; Hu, Chenming (1999). MOSFET modeling & BSIM3 user's guide. Springer. ISBN978-0-7923-8575-2.. The most recent version of the BSIM model is described in V., Sriramkumar; Paydavosi, Navid; Lu, Darsen; Lin, Chung-Hsun; Dunga, Mohan; Yao, Shijing; Morshed, Tanvir; Niknejad, Ali & Hu, Chenming (2012). 'BSIM-CMG 106.1.0beta Multi-Gate MOSFET Compact Model'(PDF). Department of EE and CS, UC Berkeley. Archived from the original(PDF) on 2014-07-27. Retrieved 2012-04-01.
80. ^Gray, P. R.; Hurst, P. J.; Lewis, S. H. & Meyer, R. G. (2001). Analysis and Design of Analog Integrated Circuits (Fourth ed.). New York: Wiley. pp. 66–67. ISBN978-0-471-32168-2.
81. ^van der Meer, P. R.; van Staveren, A.; van Roermund, A. H. M. (2004). Low-Power Deep Sub-Micron CMOS Logic: Subthreshold Current Reduction. Dordrecht: Springer. p. 78. ISBN978-1-4020-2848-9.
82. ^Degnan, Brian. 'Wikipedia fails subvt'.
83. ^Mead, Carver (1989). Analog VLSI and Neural Systems. Reading, MA: Addison-Wesley. p. 370. ISBN9780201059922.
84. ^Smith, Leslie S.; Hamilton, Alister (1998). Neuromorphic Systems: Engineering Silicon from Neurobiology. World Scientific. pp. 52–56. ISBN978-981-02-3377-8.
85. ^Kumar, Satish (2004). Neural Networks: A Classroom Approach. Tata McGraw-Hill. p. 688. ISBN978-0-07-048292-0.
86. ^Glesner, Manfred; Zipf, Peter; Renovell, Michel (2002). Field-programmable Logic and Applications: 12th International Conference. Dordrecht: Springer. p. 425. ISBN978-3-540-44108-3.
87. ^Vittoz, Eric A. (1996). 'The Fundamentals of Analog Micropower Design'. In Toumazou, Chris; Battersby, Nicholas C.; Porta, Sonia (eds.). Circuits and systems tutorials. John Wiley and Sons. pp. 365–372. ISBN978-0-7803-1170-1.
88. ^Shukla, Sandeep K.; Bahar, R. Iris (2004). Nano, Quantum and Molecular Computing. Springer. p. 10 and Fig. 1.4, p. 11. ISBN978-1-4020-8067-8.
89. ^Srivastava, Ashish; Sylvester, Dennis; Blaauw, David (2005). Statistical Analysis and Optimization For VLSI: Timing and Power. Springer. p. 135. ISBN978-0-387-25738-9.
90. ^Galup-Montoro, C. & M.C., Schneider (2007). MOSFET modeling for circuit analysis and design. London/Singapore: World Scientific. p. 83. ISBN978-981-256-810-6.
91. ^Malik, Norbert R. (1995). Electronic circuits: analysis, simulation, and design. Englewood Cliffs, NJ: Prentice Hall. pp. 315–316. ISBN978-0-02-374910-0.
92. ^Gray, P. R.; Hurst, P. J.; Lewis, S. H.; Meyer, R. G. (2001). §1.5.2 p. 45. ISBN978-0-471-32168-2.
93. ^Sedra, A. S. & Smith, K. C. (2004). Microelectronic circuits (Fifth ed.). New York: Oxford. p. 552. ISBN978-0-19-514251-8.
94. ^Sedra, A. S. & Smith, K.C. (2004). p. 250, Eq. 4.14. ISBN978-0-19-514251-8.
95. ^For a uniformly doped p-type substrate with bulk acceptor doping of N_A per unit volume,

    ${\displaystyle {\phi }_B=\frac{k_{B}T}{q}\ln \left(\frac{N_A}{n_i}\right),}$

    with n_i the intrinsic mobile carrier density per unit volume in the bulk. See, for example, Arora, Narain (2007). 'Equation 5.12'. Mosfet modeling for VLSI simulation: theory and practice. World Scientific. p. 173. ISBN978-981-256-862-5.
96. ^'Body effect'. Equars.com. Archived from the original on 2014-11-10. Retrieved 2012-06-02.
97. ^'Electronic Circuit Symbols'. circuitstoday.com. 9 November 2011. Archived from the original on 13 October 2014.
98. ^IEEE Std 315-1975 — Graphic Symbols for Electrical and Electronics Diagrams (Including Reference Designation Letters)
99. ^Jaeger, Richard C.; Blalock, Travis N. 'Figure 4.15 IEEE Standard MOS transistor circuit symbols'(PDF). Microelectronic Circuit Design.
100. ^Sze, Simon M. (2002). Semiconductor Devices: Physics and Technology(PDF) (2nd ed.). Wiley. p. 4. ISBN0-471-33372-7.
101. ^ ^abc'1978: Double-well fast CMOS SRAM (Hitachi)'(PDF). Semiconductor History Museum of Japan. Retrieved 5 July 2019.
102. ^'Computer History Museum – The Silicon Engine | 1963 – Complementary MOS Circuit Configuration is Invented'. Computerhistory.org. Retrieved 2012-06-02.
103. ^ ^ab'1963: Complementary MOS Circuit Configuration is Invented'. Computer History Museum. Retrieved 6 July 2019.
104. ^D. Kahng and S. M. Sze, 'A floating-gate and its application to memory devices', The Bell System Technical Journal, vol. 46, no. 4, 1967, pp. 1288–1295
105. ^'Depletion Mode'. Techweb. Techweb. 29 January 2010. Retrieved 27 November 2010.
106. ^'MIS'. Semiconductor Glossary.
107. ^Hadziioannou, Georges; Malliaras, George G. (2007). Semiconducting polymers: chemistry, physics and engineering. Wiley-VCH. ISBN978-3-527-31271-9.
108. ^ ^abJones, William (1997). Organic Molecular Solids: Properties and Applications. CRC Press. ISBN978-0-8493-9428-7.
109. ^Xu, Wentao; Guo, Chang; Rhee, Shi-Woo (2013). 'High performance organic field-effect transistors using cyanoethyl pullulan (CEP) high-k polymer cross-linked with trimethylolpropane triglycidyl ether (TTE) at low temperatures'. Journal of Materials Chemistry C. 1 (25): 3955. doi:10.1039/C3TC30134F.
110. ^Weimer, Paul K. (1962). 'The TFT A New Thin-Film Transistor'. Proceedings of the IRE. 50 (6): 1462–1469. doi:10.1109/JRPROC.1962.288190. ISSN0096-8390.
111. ^Kawamoto, H. (2012). 'The Inventors of TFT Active-Matrix LCD Receive the 2011 IEEE Nishizawa Medal'. Journal of Display Technology. 8 (1): 3–4. doi:10.1109/JDT.2011.2177740. ISSN1551-319X.
112. ^Castellano, Joseph A. (2005). Liquid Gold: The Story of Liquid Crystal Displays and the Creation of an Industry. World Scientific. pp. 176–7. ISBN9789812389565.
113. ^Baliga, B. Jayant (1996). Power Semiconductor Devices. Boston: PWS publishing Company. ISBN978-0-534-94098-0.
114. ^'Power MOSFET Basics: Understanding MOSFET Characteristics Associated With The Figure of Merit'. element14. Archived from the original on 5 April 2015. Retrieved 27 November 2010.
115. ^'Power MOSFET Basics: Understanding Gate Charge and Using It To Assess Switching Performance'. element14. Archived from the original on 30 June 2014. Retrieved 27 November 2010.
116. ^Irwin, J. David (1997). The Industrial Electronics Handbook. CRC Press. p. 218. ISBN9780849383434.
117. ^ ^ab'Power MOSFET Basics'(PDF). Alpha & Omega Semiconductor. Retrieved 29 July 2019.
118. ^'IGBT Definition'. PC Magazine Encyclopedia. PC Magazine. Retrieved 17 August 2019.
119. ^Zeitzoff, P. M.; Hutchby, J. A.; Huff, H. R. (2002). 'Figure 12: Simplified cross section of FinFET double-gate MOSFET.'. In Park, Yoon-Soo; Shur, Michael; Tang, William (eds.). Frontiers in electronics: future chips : proceedings of the 2002 Workshop on Frontiers in Electronics (WOFE-02), St Croix, Virgin Islands, USA, 6–11 January 2002. World Scientific. p. 82. ISBN978-981-238-222-1.
120. ^Lee, J.-H.; Lee, J.-W.; Jung, H.-A.-R.; Choi, B.-K. (2009). 'Comparison of SOI FinFETs and bulk FinFETs: Figure 2'. Silicon-on-Insulator Technology and Devices. The Electrochemical Society. p. 102. ISBN978-1-56677-712-4.
121. ^Colinge, J.P. (2008). FinFETs and Other Multi-Gate Transistors. Springer Science & Business Media. p. 11. ISBN9780387717517.
122. ^Sekigawa, Toshihiro; Hayashi, Yutaka (1 August 1984). 'Calculated threshold-voltage characteristics of an XMOS transistor having an additional bottom gate'. Solid-State Electronics. 27 (8): 827–828. Bibcode:1984SSEle..27..827S. doi:10.1016/0038-1101(84)90036-4. ISSN0038-1101.
123. ^Masuoka, Fujio; Takato, H.; Sunouchi, K.; Okabe, N.; Nitayama, A.; Hieda, K.; Horiguchi, F. (December 1988). 'High performance CMOS surrounding-gate transistor (SGT) for ultra high density LSIs'. Technical Digest., International Electron Devices Meeting: 222–225. doi:10.1109/IEDM.1988.32796.
124. ^Brozek, Tomasz (2017). Micro- and Nanoelectronics: Emerging Device Challenges and Solutions. CRC Press. p. 117. ISBN9781351831345.
125. ^'IEEE Andrew S. Grove Award Recipients'. IEEE Andrew S. Grove Award. Institute of Electrical and Electronics Engineers. Retrieved 4 July 2019.
126. ^'The Breakthrough Advantage for FPGAs with Tri-Gate Technology'(PDF). Intel. 2014. Retrieved 4 July 2019.
127. ^Tsu‐Jae King, Liu (June 11, 2012). 'FinFET: History, Fundamentals and Future'. University of California, Berkeley. Symposium on VLSI Technology Short Course. Retrieved 9 July 2019.
128. ^'MOSFET DIFFERENTIAL AMPLIFIER'(PDF). Boston University. Retrieved 10 August 2019.
129. ^'Computer History Museum – The Silicon Engine | 1955 – Photolithography Techniques Are Used to Make Silicon Devices'. Computerhistory.org. Retrieved 2012-06-02.
130. ^'1964 – First Commercial MOS IC Introduced'. Computer History Museum.
131. ^Kilby, J. S. (2007). 'Miniaturized electronic circuits [US Patent No. 3,138, 743]'. IEEE Solid-State Circuits Society Newsletter. 12 (2): 44–54. doi:10.1109/N-SSC.2007.4785580. ISSN1098-4232.
132. ^'1968: Silicon Gate Technology Developed for ICs'. Computer History Museum. Retrieved 22 July 2019.
133. ^ ^abHittinger, William C. (1973). 'METAL-OXIDE-SEMICONDUCTOR TECHNOLOGY'. Scientific American. 229 (2): 48–59. Bibcode:1973SciAm.229b..48H. doi:10.1038/scientificamerican0873-48. ISSN0036-8733. JSTOR24923169.
134. ^ ^abNigel Tout. 'Sharp QT-8D 'micro Compet''. Vintage Calculators Web Museum. Retrieved September 29, 2010.
135. ^ ^abc'Hand-held Calculators'. Vintage Calculators Web Museum. Retrieved 22 July 2019.
136. ^'Design News'. Design News. Cahners Publishing Company. 27 (1–8): 275. 1972. Today, under contracts with some 20 major companies, we're working on nearly 30 product programs—applications of MOS/LSI technology for automobiles, trucks, appliances, business machines, musical instruments, computer peripherals, cash registers, calculators, data transmission and telecommunication equipment.
137. ^Schwarz, A. F. (2014). Handbook of VLSI Chip Design and Expert Systems. Academic Press. p. 16. ISBN9781483258058.
138. ^'1971: Microprocessor Integrates CPU Function onto a Single Chip'. The Silicon Engine. Computer History Museum. Retrieved 22 July 2019.
139. ^Cushman, Robert H. (20 September 1975). '2-1/2-generation μP's-$10 parts that perform like low-end mini's'(PDF). EDN.
140. ^'Computer History Museum – Exhibits – Microprocessors'. Computerhistory.org. Retrieved 2012-06-02.
141. ^O'Neill, A. (2008). 'Asad Abidi Recognized for Work in RF-CMOS'. IEEE Solid-State Circuits Society Newsletter. 13 (1): 57–58. doi:10.1109/N-SSC.2008.4785694. ISSN1098-4232.
142. ^ ^ab'Power Supply Technology - Buck DC/DC Converters'. Mouser Electronics. Retrieved 11 August 2019.
143. ^Grant, Duncan Andrew; Gowar, John (1989). Power MOSFETS: theory and applications. Wiley. p. 239. ISBN9780471828679.
144. ^Patel, Mukund R. (2004). Spacecraft Power Systems. CRC Press. p. 97. ISBN9781420038217.
145. ^Amos, S. W.; James, Mike (2013). Principles of Transistor Circuits: Introduction to the Design of Amplifiers, Receivers and Digital Circuits. Elsevier. p. 332. ISBN9781483293905.
146. ^Grabinski, Wladyslaw; Gneiting, Thomas (2010). POWER/HVMOS Devices Compact Modeling. Springer Science & Business Media. pp. 33–4. ISBN9789048130467.
147. ^Chee, Kuan W. A.; Ye, Tianhong (August 2018). 'Towards New Generation Power MOSFETs for Automotive Electric Control Units'. Complementary Metal Oxide Semiconductor. pp. 129–32. doi:10.5772/intechopen.70906. ISBN9781789234961.
148. ^'Applying MOSFETs to Today's Power-Switching Designs'. Electronic Design. 23 May 2016. Retrieved 10 August 2019.
149. ^Carbone, James (September–October 2018). 'Buyers can expect 30-week lead times and higher tags to continue for MOSFETs'(PDF). Electronics Sourcing: 18–19.
150. ^'Automotive Power MOSFETs'(PDF). Fuji Electric. Retrieved 10 August 2019.
151. ^'NIHF Inductee Bantval Jayant Baliga Invented IGBT Technology'. National Inventors Hall of Fame. Retrieved 17 August 2019.
152. ^White, H. D.; Lokerson, D. C. (1971). 'The Evolution of IMP Spacecraft Mosfet Data Systems'. IEEE Transactions on Nuclear Science. 18 (1): 233–236. doi:10.1109/TNS.1971.4325871. ISSN0018-9499.
153. ^Interplanetary Monitoring Platform(PDF). NASA. 29 August 1989. pp. 1, 11, 134. Retrieved 12 August 2019.
154. ^Meltzer, Michael (2015). The Cassini-Huygens Visit to Saturn: An Historic Mission to the Ringed Planet. Springer. p. 70. ISBN9783319076089.
155. ^Solid State Design - Vol. 6. Horizon House. 1965.
156. ^ ^ab'DRAM'. IBM100. IBM. 9 August 2017. Retrieved 20 September 2019.
157. ^'Robert Dennard'. Encyclopedia Britannica. Retrieved 8 July 2019.
158. ^'1970: MOS Dynamic RAM Competes with Magnetic Core Memory on Price'. Computer History Museum. Retrieved 29 July 2019.
159. ^'People'. The Silicon Engine. Computer History Museum. Retrieved 17 August 2019.
160. ^'1971: Reusable semiconductor ROM introduced'. Computer History Museum. Retrieved 19 June 2019.
161. ^Bez, R.; Pirovano, A. (2019). Advances in Non-Volatile Memory and Storage Technology. Woodhead Publishing. ISBN9780081025857.
162. ^Jun-ichi Wakabayashi; Shinji Kawaji (1978). 'Hall effect in silicon MOS inversion layers under strong magnetic fields'. J. Phys. Soc. Jpn. 44 (6): 1839. Bibcode:1978JPSJ...44.1839W. doi:10.1143/JPSJ.44.1839.
163. ^K. v. Klitzing; G. Dorda; M. Pepper (1980). 'New method for high-accuracy determination of the fine-structure constant based on quantized Hall resistance'. Phys. Rev. Lett. 45 (6): 494–497. Bibcode:1980PhRvL..45..494K. doi:10.1103/PhysRevLett.45.494.
164. ^Boyle, William S; Smith, George E. (1970). 'Charge Coupled Semiconductor Devices'. Bell Syst. Tech. J. 49 (4): 587–593. doi:10.1002/j.1538-7305.1970.tb01790.x.
165. ^Matsumoto, Kazuya; et al. (1985). 'A new MOS phototransistor operating in a non-destructive readout mode'. Japanese Journal of Applied Physics. 24 (5A): L323. Bibcode:1985JaJAP..24L.323M. doi:10.1143/JJAP.24.L323.
166. ^Eric R. Fossum (1993), 'Active Pixel Sensors: Are CCD's Dinosaurs?' Proc. SPIE Vol. 1900, p. 2–14, Charge-Coupled Devices and Solid State Optical Sensors III, Morley M. Blouke; Ed.
167. ^'ReVera's FinFET Control'. revera.com. Archived from the original on 19 September 2010.
168. ^Colinge, Jean-Pierre; Colinge, Cynthia A. (2002). Physics of Semiconductor Devices. Dordrecht: Springer. p. 233, Figure 7.46. ISBN978-1-4020-7018-1.
169. ^Weber, Eicke R.; Dabrowski, Jarek, eds. (2004). Predictive Simulation of Semiconductor Processing: Status and Challenges. Dordrecht: Springer. p. 5, Figure 1.2. ISBN978-3-540-20481-7.
170. ^'International Technology Roadmap for Semiconductors'. Archived from the original on 2015-12-28.
171. ^Shilov, Anton. 'Samsung Completes Development of 5nm EUV Process Technology'. www.anandtech.com. Retrieved 2019-05-31.
172. ^Shilov, Anton. 'TSMC: First 7nm EUV Chips Taped Out, 5nm Risk Production in Q2 2019'.
173. ^'1965 – 'Moore's Law' Predicts the Future of Integrated Circuits'. Computer History Museum.
174. ^Roy, Kaushik; Yeo, Kiat Seng (2004). Low Voltage, Low Power VLSI Subsystems. McGraw-Hill Professional. Fig. 2.1, p. 44, Fig. 1.1, p. 4. ISBN978-0-07-143786-8.
175. ^Vasileska, Dragica; Goodnick, Stephen (2006). Computational Electronics. Morgan & Claypool. p. 103. ISBN978-1-59829-056-1.
176. ^'Frontier Semiconductor Paper'(PDF). Archived from the original(PDF) on February 27, 2012. Retrieved 2012-06-02.
177. ^Chen, Wai-Kai (2006). The VLSI Handbook. CRC Press. Fig. 2.28, p. 2–22. ISBN978-0-8493-4199-1.
178. ^Lindsay, R.; Pawlak; Kittl; Henson; Torregiani; Giangrandi; Surdeanu; Vandervorst; Mayur; Ross; McCoy; Gelpey; Elliott; Pages; Satta; Lauwers; Stolk; Maex (2011). 'A Comparison of Spike, Flash, SPER and Laser Annealing for 45nm CMOS'. MRS Proceedings. 765. doi:10.1557/PROC-765-D7.4.
179. ^'VLSI wiring capacitance'(PDF). IBM Journal of Research and Development.^{[dead link]}
180. ^Soudris, D.; Pirsch, P.; Barke, E., eds. (2000). Integrated Circuit Design: Power and Timing Modeling, Optimization, and Simulation (10th Int. Workshop). Springer. p. 38. ISBN978-3-540-41068-3.
181. ^Orshansky, Michael; Nassif, Sani; Boning, Duane (2007). Design for Manufacturability And Statistical Design: A Constructive Approach. New York 309284: Springer. ISBN9780387309286.
182. ^ ^abc'Is 14nm the end of the road for silicon chips?'. ExtremeTech. September 27, 2011. Retrieved 26 September 2019.
183. ^ ^abAtalla, Mohamed M.; Kahng, Dawon (June 1960). 'Silicon–silicon dioxide field induced surface devices'. IRE-AIEE Solid State Device Research Conference. Carnegie Mellon University Press.
184. ^Sze, Simon M. (2002). Semiconductor Devices: Physics and Technology(PDF) (2nd ed.). Wiley. p. 4. ISBN0-471-33372-7.
185. ^Lojek, Bo (2007). History of Semiconductor Engineering. Springer Science & Business Media. pp. 326–7. ISBN9783540342588.
186. ^Heiman, Frederic P.; Hofstein, Steven R. (October 1962). 'The insulated-gate field-effect transistor'. 1962 International Electron Devices Meeting: 58–58. doi:10.1109/IEDM.1962.187313.
187. ^Lojek, Bo (2007). History of Semiconductor Engineering. Springer Science & Business Media. p. 334. ISBN9783540342588.
188. ^Sah, Chih-Tang; Leistiko, Otto; Grove, A. S. (May 1965). 'Electron and hole mobilities in inversion layers on thermally oxidized silicon surfaces'. IEEE Transactions on Electron Devices. 12 (5): 248–254. doi:10.1109/T-ED.1965.15489.
189. ^Dennard, Robert H.; Gaensslen, Fritz H.; Yu, Hwa-Nien; Kuhn, L. (December 1972). 'Design of micron MOS switching devices'. 1972 International Electron Devices Meeting: 168–170. doi:10.1109/IEDM.1972.249198.
190. ^ ^abHori, Ryoichi; Masuda, Hiroo; Minato, Osamu; Nishimatsu, Shigeru; Sato, Kikuji; Kubo, Masaharu (September 1975). 'Short Channel MOS-IC Based on Accurate Two Dimensional Device Design'. Japanese Journal of Applied Physics. 15 (S1): 193. doi:10.7567/JJAPS.15S1.193. ISSN1347-4065.
191. ^Critchlow, D. L. (2007). 'Recollections on MOSFET Scaling'. IEEE Solid-State Circuits Society Newsletter. 12 (1): 19–22. doi:10.1109/N-SSC.2007.4785536.
192. ^'1970s: Development and evolution of microprocessors'(PDF). Semiconductor History Museum of Japan. Retrieved 27 June 2019.
193. ^'NEC 751 (uCOM-4)'. The Antique Chip Collector's Page. Archived from the original on 2011-05-25. Retrieved 2010-06-11.
194. ^'1973: 12-bit engine-control microprocessor (Toshiba)'(PDF). Semiconductor History Museum of Japan. Retrieved 27 June 2019.
195. ^Belzer, Jack; Holzman, Albert G.; Kent, Allen (1978). Encyclopedia of Computer Science and Technology: Volume 10 - Linear and Matrix Algebra to Microorganisms: Computer-Assisted Identification. CRC Press. p. 402. ISBN9780824722609.
196. ^Dennard, Robert H.; Gaensslen, F. H.; Yu, Hwa-Nien; Rideout, V. L.; Bassous, E.; LeBlanc, A. R. (October 1974). 'Design of ion-implanted MOSFET's with very small physical dimensions'(PDF). IEEE Journal of Solid-State Circuits. 9 (5): 256–268. doi:10.1109/JSSC.1974.1050511.
197. ^Kubo, Masaharu; Hori, Ryoichi; Minato, Osamu; Sato, Kikuji (February 1976). 'A threshold voltage controlling circuit for short channel MOS integrated circuits'. 1976 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. XIX: 54–55. doi:10.1109/ISSCC.1976.1155515.
198. ^'Intel® Microprocessor Quick Reference Guide'. Intel. Retrieved 27 June 2019.
199. ^Hunter, William R.; Ephrath, L. M.; Cramer, Alice; Grobman, W. D.; Osburn, C. M.; Crowder, B. L.; Luhn, H. E. (April 1979). '1 /spl mu/m MOSFET VLSI technology. V. A single-level polysilicon technology using electron-beam lithography'. IEEE Journal of Solid-State Circuits. 14 (2): 275–281. doi:10.1109/JSSC.1979.1051174.
200. ^Kobayashi, Toshio; Horiguchi, Seiji; Kiuchi, K. (December 1984). 'Deep-submicron MOSFET characteristics with 5 nm gate oxide'. 1984 International Electron Devices Meeting: 414–417. doi:10.1109/IEDM.1984.190738.
201. ^Kobayashi, Toshio; Horiguchi, Seiji; Miyake, M.; Oda, M.; Kiuchi, K. (December 1985). 'Extremely high transconductance (above 500 mS/mm) MOSFET with 2.5 nm gate oxide'. 1985 International Electron Devices Meeting: 761–763. doi:10.1109/IEDM.1985.191088.
202. ^Chou, Stephen Y.; Antoniadis, Dimitri A.; Smith, Henry I. (December 1985). 'Observation of electron velocity overshoot in sub-100-nm-channel MOSFET's in Silicon'. IEEE Electron Device Letters. 6 (12): 665–667. doi:10.1109/EDL.1985.26267.
203. ^ ^abChou, Stephen Y.; Smith, Henry I.; Antoniadis, Dimitri A. (January 1986). 'Sub‐100‐nm channel‐length transistors fabricated using x‐ray lithography'. Journal of Vacuum Science & Technology B: Microelectronics Processing and Phenomena. 4 (1): 253–255. doi:10.1116/1.583451. ISSN0734-211X.
204. ^Kobayashi, Toshio; Miyake, M.; Deguchi, K.; Kimizuka, M.; Horiguchi, Seiji; Kiuchi, K. (1987). 'Subhalf-micrometer p-channel MOSFET's with 3.5-nm gate Oxide fabricated using X-ray lithography'. IEEE Electron Device Letters. 8 (6): 266–268. doi:10.1109/EDL.1987.26625.
205. ^Sah, Chih-Tang; Wanlass, Frank (February 1963). 'Nanowatt logic using field-effect metal-oxide semiconductor triodes'. 1963 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. VI: 32–33. doi:10.1109/ISSCC.1963.1157450.
206. ^ ^abLojek, Bo (2007). History of Semiconductor Engineering. Springer Science & Business Media. p. 330. ISBN9783540342588.
207. ^Aitken, A.; Poulsen, R. G.; MacArthur, A. T. P.; White, J. J. (December 1976). 'A fully plasma etched-ion implanted CMOS process'. 1976 International Electron Devices Meeting: 209–213. doi:10.1109/IEDM.1976.189021.
208. ^Masuhara, Toshiaki; Minato, Osamu; Sasaki, Toshio; Sakai, Yoshio; Kubo, Masaharu; Yasui, Tokumasa (February 1978). 'A high-speed, low-power Hi-CMOS 4K static RAM'. 1978 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. XXI: 110–111. doi:10.1109/ISSCC.1978.1155749.
209. ^Masuhara, Toshiaki; Minato, Osamu; Sakai, Yoshi; Sasaki, Toshio; Kubo, Masaharu; Yasui, Tokumasa (September 1978). 'Short Channel Hi-CMOS Device and Circuits'. ESSCIRC 78: 4th European Solid State Circuits Conference - Digest of Technical Papers: 131–132.
210. ^ ^abcdeGealow, Jeffrey Carl (10 August 1990). 'Impact of Processing Technology on DRAM Sense Amplifier Design'(PDF). CORE. Massachusetts Institute of Technology. pp. 149–166. Retrieved 25 June 2019.
211. ^Chwang, R. J. C.; Choi, M.; Creek, D.; Stern, S.; Pelley, P. H.; Schutz, Joseph D.; Bohr, M. T.; Warkentin, P. A.; Yu, K. (February 1983). 'A 70ns high density CMOS DRAM'. 1983 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. XXVI: 56–57. doi:10.1109/ISSCC.1983.1156456.
212. ^Mano, Tsuneo; Yamada, J.; Inoue, Junichi; Nakajima, S. (February 1983). 'Submicron VLSI memory circuits'. 1983 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. XXVI: 234–235. doi:10.1109/ISSCC.1983.1156549.
213. ^Hu, G. J.; Taur, Yuan; Dennard, Robert H.; Terman, L. M.; Ting, Chung-Yu (December 1983). 'A self-aligned 1-µm CMOS technology for VLSI'. 1983 International Electron Devices Meeting: 739–741. doi:10.1109/IEDM.1983.190615.
214. ^Sumi, T.; Taniguchi, Tsuneo; Kishimoto, Mikio; Hirano, Hiroshige; Kuriyama, H.; Nishimoto, T.; Oishi, H.; Tetakawa, S. (1987). 'A 60ns 4Mb DRAM in a 300mil DIP'. 1987 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. XXX: 282–283. doi:10.1109/ISSCC.1987.1157106.
215. ^Mano, Tsuneo; Yamada, J.; Inoue, Junichi; Nakajima, S.; Matsumura, Toshiro; Minegishi, K.; Miura, K.; Matsuda, T.; Hashimoto, C.; Namatsu, H. (1987). 'Circuit technologies for 16Mb DRAMs'. 1987 IEEE International Solid-State Circuits Conference. Digest of Technical Papers. XXX: 22–23. doi:10.1109/ISSCC.1987.1157158.
216. ^Hanafi, Hussein I.; Dennard, Robert H.; Taur, Yuan; Haddad, Nadim F.; Sun, J. Y. C.; Rodriguez, M. D. (September 1987). '0.5 μm CMOS Device Design and Characterization'. ESSDERC '87: 17th European Solid State Device Research Conference: 91–94.
217. ^Kasai, Naoki; Endo, Nobuhiro; Kitajima, Hiroshi (December 1987). '0.25 µm CMOS technology using P+polysilicon gate PMOSFET'. 1987 International Electron Devices Meeting: 367–370. doi:10.1109/IEDM.1987.191433.
218. ^Inoue, M.; Kotani, H.; Yamada, T.; Yamauchi, Hiroyuki; Fujiwara, A.; Matsushima, J.; Akamatsu, Hironori; Fukumoto, M.; Kubota, M.; Nakao, I.; Aoi (1988). 'A 16mb Dram with an Open Bit-Line Architecture'. 1988 IEEE International Solid-State Circuits Conference, 1988 ISSCC. Digest of Technical Papers: 246–. doi:10.1109/ISSCC.1988.663712.
219. ^Shahidi, Ghavam G.; Davari, Bijan; Taur, Yuan; Warnock, James D.; Wordeman, Matthew R.; McFarland, P. A.; Mader, S. R.; Rodriguez, M. D. (December 1990). 'Fabrication of CMOS on ultrathin SOI obtained by epitaxial lateral overgrowth and chemical-mechanical polishing'. International Technical Digest on Electron Devices: 587–590. doi:10.1109/IEDM.1990.237130.
220. ^'Memory'. STOL (Semiconductor Technology Online). Retrieved 25 June 2019.
221. ^'0.18-micron Technology'. TSMC. Retrieved 30 June 2019.
222. ^Sekigawa, Toshihiro; Hayashi, Yutaka (August 1984). 'Calculated threshold-voltage characteristics of an XMOS transistor having an additional bottom gate'. Solid-State Electronics. 27 (8): 827–828. doi:10.1016/0038-1101(84)90036-4. ISSN0038-1101.
223. ^Koike, Hanpei; Nakagawa, Tadashi; Sekigawa, Toshiro; Suzuki, E.; Tsutsumi, Toshiyuki (23 February 2003). 'Primary Consideration on Compact Modeling of DG MOSFETs with Four-terminal Operation Mode'(PDF). TechConnect Briefs. 2 (2003): 330–333.
224. ^Davari, Bijan; Chang, Wen-Hsing; Wordeman, Matthew R.; Oh, C. S.; Taur, Yuan; Petrillo, Karen E.; Rodriguez, M. D. (December 1988). 'A high performance 0.25 mu m CMOS technology'. Technical Digest., International Electron Devices Meeting: 56–59. doi:10.1109/IEDM.1988.32749.
225. ^Davari, Bijan; Wong, C. Y.; Sun, Jack Yuan-Chen; Taur, Yuan (December 1988). 'Doping of n/sup +/ and p/sup +/ polysilicon in a dual-gate CMOS process'. Technical Digest., International Electron Devices Meeting: 238–241. doi:10.1109/IEDM.1988.32800.
226. ^Masuoka, Fujio; Takato, Hiroshi; Sunouchi, Kazumasa; Okabe, N.; Nitayama, Akihiro; Hieda, K.; Horiguchi, Fumio (December 1988). 'High performance CMOS surrounding-gate transistor (SGT) for ultra high density LSIs'. Technical Digest., International Electron Devices Meeting: 222–225. doi:10.1109/IEDM.1988.32796.
227. ^Brozek, Tomasz (2017). Micro- and Nanoelectronics: Emerging Device Challenges and Solutions. CRC Press. p. 117. ISBN9781351831345.
228. ^Ishikawa, Fumitaro; Buyanova, Irina (2017). Novel Compound Semiconductor Nanowires: Materials, Devices, and Applications. CRC Press. p. 457. ISBN9781315340722.
229. ^Colinge, J.P. (2008). FinFETs and Other Multi-Gate Transistors. Springer Science & Business Media. p. 11. ISBN9780387717517.
230. ^Hisamoto, Digh; Kaga, Toru; Kawamoto, Yoshifumi; Takeda, Eiji (December 1989). 'A fully depleted lean-channel transistor (DELTA)-a novel vertical ultra thin SOI MOSFET'. International Technical Digest on Electron Devices Meeting: 833–836. doi:10.1109/IEDM.1989.74182.
231. ^'IEEE Andrew S. Grove Award Recipients'. IEEE Andrew S. Grove Award. Institute of Electrical and Electronics Engineers. Retrieved 4 July 2019.
232. ^Weimer, Paul K. (June 1962). 'The TFT A New Thin-Film Transistor'. Proceedings of the IRE. 50 (6): 1462–1469. doi:10.1109/JRPROC.1962.288190. ISSN0096-8390.
233. ^Brody, T. P.; Kunig, H. E. (October 1966). 'A HIGH‐GAIN InAs THIN‐FILM TRANSISTOR'. Applied Physics Letters. 9 (7): 259–260. doi:10.1063/1.1754740. ISSN0003-6951.
234. ^Woodall, Jerry M. (2010). Fundamentals of III-V Semiconductor MOSFETs. Springer Science & Business Media. pp. 2–3. ISBN9781441915474.
235. ^Kahng, Dawon; Sze, Simon Min (July–August 1967). 'A floating gate and its application to memory devices'. The Bell System Technical Journal. 46 (6): 1288–1295. doi:10.1002/j.1538-7305.1967.tb01738.x.
236. ^Lin, Hung Chang; Iyer, Ramachandra R. (July 1968). 'A Monolithic Mos-Bipolar Audio Amplifier'. IEEE Transactions on Broadcast and Television Receivers. 14 (2): 80–86. doi:10.1109/TBTR1.1968.4320132.
237. ^ ^abAlvarez, Antonio R. (1990). 'Introduction To BiCMOS'. BiCMOS Technology and Applications. Springer Science & Business Media. pp. 1-20 (2). doi:10.1007/978-1-4757-2029-7_1. ISBN9780792393849.
238. ^Lin, Hung Chang; Iyer, Ramachandra R.; Ho, C. T. (October 1968). 'Complementary MOS-bipolar structure'. 1968 International Electron Devices Meeting: 22–24. doi:10.1109/IEDM.1968.187949.
239. ^ ^ab'Advances in Discrete Semiconductors March On'. Power Electronics Technology. Informa: 52–6. September 2005. Archived(PDF) from the original on 22 March 2006. Retrieved 31 July 2019.
240. ^Oxner, E. S. (1988). Fet Technology and Application. CRC Press. p. 18. ISBN9780824780500.
241. ^Tarui, Y.; Hayashi, Y.; Sekigawa, Toshihiro (September 1969). 'Diffusion Self-Aligned MOST; A New Approach for High Speed Device'. Proceedings of the 1st Conference on Solid State Devices. doi:10.7567/SSDM.1969.4-1.
242. ^McLintock, G. A.; Thomas, R. E. (December 1972). 'Modelling of the double-diffused MOST's with self-aligned gates'. 1972 International Electron Devices Meeting: 24–26. doi:10.1109/IEDM.1972.249241.
243. ^Tarui, Y.; Hayashi, Y.; Sekigawa, Toshihiro (October 1970). 'DSA enhancement - Depletion MOS IC'. 1970 International Electron Devices Meeting: 110–110. doi:10.1109/IEDM.1970.188299.
244. ^Duncan, Ben (1996). High Performance Audio Power Amplifiers(PDF). Elsevier. pp. 177–8, 406. ISBN9780080508047.
245. ^Baliga, B. Jayant (2015). The IGBT Device: Physics, Design and Applications of the Insulated Gate Bipolar Transistor. William Andrew. pp. xxviii, 5–12. ISBN9781455731534.
246. ^Higuchi, H.; Kitsukawa, Goro; Ikeda, Takahide; Nishio, Y.; Sasaki, N.; Ogiue, Katsumi (December 1984). 'Performance and structures of scaled-down bipolar devices merged with CMOSFETs'. 1984 International Electron Devices Meeting: 694–697. doi:10.1109/IEDM.1984.190818.
247. ^Deguchi, K.; Komatsu, Kazuhiko; Miyake, M.; Namatsu, H.; Sekimoto, M.; Hirata, K. (1985). 'Step-and-Repeat X-ray/Photo Hybrid Lithography for 0.3 μm Mos Devices'. 1985 Symposium on VLSI Technology. Digest of Technical Papers: 74–75.
248. ^Momose, H.; Shibata, Hideki; Saitoh, S.; Miyamoto, Jun-ichi; Kanzaki, K.; Kohyama, Susumu (1985). '1.0-/spl mu/m n-Well CMOS/Bipolar Technology'. IEEE Journal of Solid-State Circuits. 20 (1): 137–143. doi:10.1109/JSSC.1985.1052286.
249. ^Shahidi, Ghavam G.; Antoniadis, Dimitri A.; Smith, Henry I. (December 1986). 'Electron velocity overshoot at 300 K and 77 K in silicon MOSFETs with submicron channel lengths'. 1986 International Electron Devices Meeting: 824–825. doi:10.1109/IEDM.1986.191325.
250. ^Davari, Bijan; Ting, Chung-Yu; Ahn, Kie Y.; Basavaiah, S.; Hu, Chao-Kun; Taur, Yuan; Wordeman, Matthew R.; Aboelfotoh, O. (May 1987). 'Submicron Tungsten Gate MOSFET with 10 nm Gate Oxide'. 1987 Symposium on VLSI Technology. Digest of Technical Papers: 61–62.
251. ^Havemann, Robert H.; Eklund, R. E.; Tran, Hiep V.; Haken, R. A.; Scott, D. B.; Fung, P. K.; Ham, T. E.; Favreau, D. P.; Virkus, R. L. (December 1987). 'An 0.8 #181;m 256K BiCMOS SRAM technology'. 1987 International Electron Devices Meeting: 841–843. doi:10.1109/IEDM.1987.191564.

External links[edit]

Mosfet Application Circuits For Kids

• How Semiconductors and Transistors Work (MOSFETs) WeCanFigureThisOut.org
• 'Understanding power MOSFET data sheet parameters – Nexperia PDF Application Note AN11158'(PDF).
• 'An introduction to depletion-mode MOSFETs'. Archived from the original on 28 September 2008.
• 'Power MOSFETs'.
• 'Criteria for Successful Selection of IGBT and MOSFET Modules'. Archived from the original on 2012-11-12. Retrieved 2018-12-16.
• 'MOSFET Process Step by Step'. Archived from the original on 2009-08-22. Retrieved 2016-02-06. A Flash slide showing the fabricating process of a MOSFET in detail
• 'MOSFET Calculator'. Archived from the original on 2008-05-27. Retrieved 2008-06-03.
• 'Advanced MOSFET issues'. ecee.colorado.edu. 27 November 2010.
• 'MOSFET applet'.
• Nicolai, Ulrich; Reimann, Tobias; Petzoldt, Jürgen; Lutz, Josef (1998). Application Manual IGBT and MOSFET Power Modules (1st ed.). ISLE Verlag. ISBN978-3-932633-24-9. Archived from the original on 2 March 2012.
• Wintrich, Arendt; Nicolai, Ulrich; Tursky, Werner; Reimann, Tobias (2011). PDF-Version(PDF) (2nd ed.). Nuremberg: Semikron. ISBN978-3-938843-66-6. Archived from the original(PDF) on 3 September 2013.
• 'MIT Open Courseware 6.002 – Spring 2007'.
• 'MIT Open Courseware 6.012 – Fall 2009'.
• 'Georgia Tech BJT and FET Slides'.
• 'CircuitDesign: MOS Diffusion Parasitics'.
• Mark Lundstrom, Mark Lundstrom (2008). 'Course on Physics of Nanoscale Transistors'.Cite journal requires |journal= (help)
• Dr. Lundstrom (2005). 'Notes on Ballistic MOSFETs'.Cite journal requires |journal= (help)

High Power Mosfet Circuit Diagrams
